Xerox Phaser 6360 Service Manual

4-16 Phaser 6300/6350/6360 Service Manual
General Troubleshooting
3 1. Disconnect the connectors J163,
J164 and J165 from the LVPS.
2. Turn the AC power switch On.
3. Verify the DC voltages between the
following pins on the LVPS:
P163-1 <=> P163-2 = +24
VDC?
P164-1 <=> P164-4 = +3.3
VDC?
P165-2 <=> P165-3 = +5
VDC?
P165-4 <=> P165-5 = +3.3
VDC?
Go to Step 4. Replace the
LVPS
(
page 8-100).
4 1. Turn the AC power switch Off.
2. Connect J164 to the LVPS then turn
the AC power switch On.
P/J164-1 <=>P/J164-4 = +3.3
VDC?
Go to Step 7. Go to Step 5.
5 Check the following parts for fault or
damage:
■ LVRPG Harness, PL10.1.3.
■ Engine Control Board, PL9.1.16
Replace if
damaged or
defective.
Go to Step 7.
6 Does the problem recur? Go to Step 7 Complete
7 1. Turn the AC power switch Off.
2. Connect J165 to the LVPS then turn
the AC power switch On.
3. Verify the DC voltages between the
following pins on the LVPS:
P/J165-2 <=> P/J165-3 = +5
VDC?
P/J165-3 <=> P/J165-4 =
+3.3 VDC?
Go to Step 10. Go to Step 8.
8 Check the LV Harness, PL10.1.2 for
fault or damage.
Replace if
damaged or
defective.
Go to Step 10.
9 Does the error recur? Go to Step 10. Complete
10 Turn the AC power Switch OFF
Connect J163 to the LVPS then turn
the AC power switch ON.
P/J163-1 <->P/J163-2 = +24 VDC?
Complete Go to Step 11.
11 Check the 24V Harness, PL10.1.1 for
fault or damage.
Replace if
damaged or
defective.
Complete
Troubleshooting Procedure Table (Continued)
Step Action and Questions Yes No

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
