Xerox Phaser 6360 Service Manual

Phaser 6300/6350/6360 Color Laser Printer Service Manual A-15
Reference
Set Default Print
Parameters
Sets print parameters to default values:
Color Mode: 4 Color, Print Mode:
Simplex, Resolution: 600 dpi, Media
Type: Plain Paper, Media Source: Tray
2, Media Coating: Normal, Media Size:
Letter. Use 'Custom Test Print' to start
printing.
Motors/Fans Tests - Tests the motors and fans one at a time.
Main Motor High Speed
Normal Speed
Half Speed
One Third Speed
High Speed Continuous
Normal Speed Continuous
Half Speed Continuous
One Third Speed Continuous
Audible verification of motor
function.
The motor tests are pulsed or
continuous.
Duplex Motor Forward High Speed
Forward Normal Speed
Forward Half Speed
Forward Slow Speed
Forward Double High Speed
Forward Double Speed
Reverse High Speed
Reverse Normal Speed
Reverse Half Speed
Reverse Slow Speed
Reverse Double High Speed
Reverse Double Speed
Fwd Fast Speed Continuous
Fwd Normal Speed Continuous
Fwd Half Speed Continuous
Fwd Slow Speed Continuous
Fwd Double High Speed Continuous
Fwd Double Speed Continuous
Rev High Speed Continuous
Rev Normal Speed Continuous
Rev Half Speed Continuous
Rev Slow Speed Continuous
Rev Double High Speed Continuous
Rev Double Speed Continuous
Audible verification of motor
function.
Fuser Motor High Speed
Normal Speed
Half Speed
Slow Speed
Normal Speed Continuous
Normal Speed Continuous
Half Speed Continuous
Slow Speed Continuous
Audible verification of motor
function.
Service Diagnostics Tests and Utilities (Continued)
Test Control Panel Display and Test Definition

Xerox Phaser 6360 Specifications

General

Depth (max)	698 mm
Depth (min)	580 mm
Height (max)	854 mm
Height (min)	513 mm
Maximum width	572 mm
Package length	933.449 mm
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	750 W
Non-operating relative humidity (non-condensing)	15 - 85 %
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	105 W
Power consumption (PowerSave)	22 W
Multi-Purpose tray	Yes
Total input capacity	1800 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Multi-Purpose tray input capacity	150 sheets
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum internal memory	1024 MB
Sound power level (standby)	34.4 dB
Operating temperature (T-T)	50 - 90 °F
Maximum duty cycle	100000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PostScript 3
Package width	609.599 mm
Package height	1498.599 mm
Package weight	83462.4 g
Custom media width	89 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	140 - 914 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Certification	CE, EMC 89/336/EEC, FCC, Low Voltage 73/23/EEC, RoHS, 2002/95/EC
Product color	Blue, White
Sustainability certificates	ENERGY STAR
