August 2015
5-37
Xerox® WorkCentre® 5890 Family
PL 11.52
Parts Lists
PL 11.52 LVF BM Docking Latch
Item Part Description
1
– Docking latch cover (Not Spared)
2 110K13980 Docking interlock switch (S11-300)
3 003K20401 Link bracket assembly
4 – Stopper (P/O PL 11.52 Item 7)
5 – Docking latch (P/O PL 11.52 Item
7)
6 – Latch hook (P/O PL 11.52 Item 7)
7 003K20410 Docking latch assembly (REP
11.16-150)
8 120K02591 Docking actuator
www MK-Electronic de
