August 2015
5-65
Xerox® WorkCentre® 5890 Family
PL 11.116
Parts Lists
PL 11.116 1K LCSS Staple Head
A
ssembly
Item Part Description
1
014K10100 Stapler assembly (REP 11.7-120)
2 – Mounting bracket (P/O PL 11.116
Item 1)
3 – Stapler harness (P/O PL 11.116
Item 1)
4 130E10380 SH1 Paper sensor (Q11-361) (REP
11.7-120)
5 – Staple head unit (P/O PL 11.116
Item 1)
6 – Stapler cover (P/O PL 11.116 Item
1)
7 – Cable clamp (P/O PL 11.116 Item
1)
8 108R00682 Staple cartridge
9 108R00535 Staple refills
