Xerox WorkCentre 5890 User Manual

August 2015
5-67
Xerox® WorkCentre® 5890 Family
PL 11.120
Parts Lists
PL 11.120 1K LCSS Bin 1 Entry
Item Part Description
1
032K04570 Left paper guide
2 032K04560 Lower right paper guide
3 – Ejector drive shaft (REF: PL 11.118
Item 1)
4 130E11440 2nd to top exit sensor (Q11-140)
5 013E25790 Nylon bearing
6 – Pulley (Not Spared)
7 115E11810 Static eliminator (stacker)
8 023E24340 Paper output drive belt (REP 11.4-
120)
9 – Upper right paper guide (Not
Spared)
10 013E37460 Bearing
11 – Belt tensioner (Not Spared)
12 – Spring (Not Spared)
13 127K55830 Transport motor 2 (MOT 11-001)
(REP 11.4-120)
14 – Mylar safety cover (P/O PL 11.120
Item 1)
