August 2015
5-95
Xerox® WorkCentre® 5890 Family
PL 11.195
Parts Lists
PL 11.195 Tri-Folder Top Door Cover
A
ssembly
Item Part Description
1
Top access cover (P/O PL 11.195
Item 10)
2 Top cover door assembly spring
(Not Spared)
3 Top cover door assembly shaft (Not
Spared)
4 Latch hook (P/O PL 11.195 Item
10)
5 Top door cover assembly base (P/O
PL 11.195 Item 10)
6 Latch handle (P/O PL 11.195 Item
10)
7 Latch spring (P/O PL 11.195 Item
10)
8 059K58690 Idler assembly (REP 11.73-171)
9 Idler spring (P/O PL 11.195 Item
10)
10 848K11680 Top cover door assembly (REP
11.73-171)
11 Idler assembly (Not Spared)
