Xerox WorkCentre 5890 User Manual

August 2015
5-3
Xerox® WorkCentre® 5890 Family
PL 1.10
Parts Lists
PL 1.10 Power and Control Assembly
Item Part Description
1
– Power and control assembly
(USSG/XCL) (Not Spared) (REP
1.1)
– – Power and control assembly (XE)
(Not Spared) (REP 1.1)
2 960K73365 IOT PWB (REP 3.1)
3 – LVPS and base module (see below
for variants) (REP 1.9)
– 105K35817 45-55 ppm (W/O TAG 013)
– 105K36402 65-90 ppm (USSG/XCL) (W/O TAG
013)
– 105K36412 65-90 ppm (XE) (W/O TAG 013)
– 105K37780 65-90 ppm (XE) (W/TAG 013)
– 105K37790 65-90 ppm (USSG/XCL) (W/TAG
013)
4 – Shield (Not Spared)
5 105K29554 HVPS (REP 1.10)
6 – Locking screw (Not Spared)
7 110K14020 Front door interlock switch (S01-
300) (NOTE) (REP 1.8)
8 962K63630 IOT internal tray 6 harness
9 108E06730 In-line fuse (2.5A slow blow)
10 – Main power cord (REF: PL 1.15
Item 1)
11 – Not used
12 962K27020 IOT - HVPS harness
13 962K49460 IOT - Finisher harness
NOTE: For the left door interlock (S01-305), refer to PL 70.30
Item 3
www MK-Electronic de

Xerox WorkCentre 5890 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 kbps
Duplex Printing	Yes
Network Connectivity	Ethernet, USB
Operating System Compatibility	Windows, Mac, Linux
Display	Touchscreen
