Xerox WorkCentre 5890 User Manual

August 2015
5-70
Xerox® WorkCentre® 5890 Family
PL 11.130
Parts Lists
PL 11.130 HVF Covers and Docking
Item Part Description
1
848K12490 Top cover (REP 11.1-171)
2 848K12501 Foot cover (REP 11.1-171)
3 848E17790 Front door (REP 11.1-171)
4 848K12510 Door support (REP 11.1-171)
5 848K12520 Rear cover (REP 11.1-171)
6 848K12530 Vent cover (REP 11.1-171)
7 848E17800 Foot cover (REP 11.1-171)
8 848E17810 Inserter removable cover (REP
11.1-171)
9 848K12540 Top tray (REP 11.3-171)
10 – Seal (Not Spared)
11 017K04830 Fixed castor assembly (REP 11.96-
171)
12 – Fixed castor bracket (P/O PL
11.130 Item 11)
13 017K04630 Adjustable castor (REP 11.96-171)
14 – Adjustable castor washer (P/O PL
11.130 Item 13)
15 017K04641 Mounting bracket assembly
16 110K13970 Docking interlock switch (S11-300)
17 120K02591 Docking actuator
