Xerox WorkCentre 7800 series User Manual

Troubleshooting
220 WorkCentre 7800 Series Multifunction Printer
User Guide
Clearing Jams at Door A
1. Remove paper from the left tray, then fold up the tray.
2. Open tray 5 as shown (1).
3. While lifting the release lever (2), open door A as shown (3).
WARNING: The area around the fuser can be hot. Use caution to avoid injury.
CAUTION: Do not touch the transfer belt. Touching the belt can reduce image quality or damage the
transfer belt. Do not touch the transfer roller. Touching the roller can reduce image quality.
