14 European Standards
YASKAWA TOEPC71061752B GA500 Drive Installation & Primary Operation 151
Drive Model
Fuse
Manufacturer:
Bussmann
Model
2021 FWH-90B
2030 FWH-100B
2042 FWH-150B
Drive Model
Fuse
Manufacturer:
Bussmann
Model
2056 FWH-200B
2070 FWH-200B
2082 FWH-225A
Table 14.8 Recommended Fuse: Three-Phase 400 V Class
Drive Model
Fuse
Manufacturer:
Bussmann
Model
4001 FWH-40B
4002 FWH-40B
4004 FWH-50B
4005 FWH-70B
4007 FWH-70B
4009 FWH-90B
4012 FWH-90B
Drive Model
Fuse
Manufacturer:
Bussmann
Model
4018 FWH-80B
4023 FWH-100B
4031 FWH-125B
4038 FWH-175B
4044 FWH-200B
4060 FWH-200B
◆ EMC Directive
Use drives with built-in EMC filters or install external EMC filters to the drive input side to
comply with the EMC Directive.
Drives with built-in EMC filters (models BxxxE, 2xxxE, 4xxxE) were tested in accordance with
European standard EN 61800-3:2004/A1:2012, and comply with the EMC Directive.
■ Install a Drive to Conform to the EMC Directive
Install drive models BxxxE, 2xxxE, and 4xxxE with this procedure to comply with the EMC
Directive when the drive is a single unit or installed in a larger device.
1. Install the drive on a grounded metal plate.
2. Wire the drive and motor.
To Next Page
