15 UL Standards
YASKAWA TOEPC71061752B GA500 Drive Installation & Primary Operation 179
■ E2-01: Motor Rated Current (FLA)
No.
(Hex.)
Name Description
Default
(Range)
E2-01
(030E)
Motor Rated
Current (FLA)
Sets the motor rated current in amps.
Determined by o2-
04, C6-01
(10% to 200% of
the drive rated
current)
Note:
• If E2-01 < E2-03 [Motor No-Load Current], the drive will detect oPE02 [Parameter Range Setting Error].
• When the drive model changes, the display units for this parameter also change.
–0.01 A: B001 to B018, 2001 to 2042, 4001 to 4023
–0.1 A: 2056 to 2082, 4031 to 4060
The value set for E2-01 becomes the reference value for motor protection and the torque limit.
Enter the motor rated current written on the motor nameplate. Auto-Tuning the drive will
automatically set E2-01 to the value input for T1-04 [Motor Rated Current].
■ E5-03: Motor Rated Current (FLA)
No.
(Hex.)
Name Description
Default
(Range)
E5-03
(032B)
Motor Rated
Current (FLA)
Sets the PM motor rated current (FLA).
Determined by o2-
04, C6-01
(10% to 200% of
the drive rated
current)
Note:
When the drive model changes, the display units for this parameter also change.
• 0.01 A: B001 to B018, 2001 to 2042, 4001 to 4023
• 0.1 A: 2056 to 2082, 4031 to 4060
The drive automatically sets E5-03 to the value input for T2-06 [PM Motor Rated Current] after
you do these types of Auto-Tuning:
• PM Motor Parameter Settings
• PM Stationary Auto-Tuning
• PM StaTun for Stator Resistance
• PM Rotational Auto-Tuning
■ E9-06: Motor Rated Current (FLA)
No.
(Hex.)
Name Description
Default
(Range)
E9-06
(11E9)
Motor Rated
Current (FLA)
Sets the motor rated current in amps.
Determined by
E9-01 and o2-04
(10% to 200% of
the drive rated
current)
Note:
When the drive model changes, the display units for this parameter also change.
• 0.01 A: B001 to B018, 2001 to 2042, 4001 to 4023
• 0.1 A: 2056 to 2082, 4031 to 4060
