YASKAWA GA50U Series User Manual

14 European Standards
YASKAWA TOEPC71061752B GA500 Drive Installation & Primary Operation 161
Drive model EMC Noise Filter Model Quantity Manufacturer
4005 FS23639-10-07 1 Schaffner
4007 FS23639-10-07 1 Schaffner
4009 FS23639-10-07 1 Schaffner
4012 FS23639-15-07 1 Schaffner
4018 FS5972-35-07
*1
1 Schaffner
4023 FS5972-35-07
*1
1 Schaffner
4031 FS5972-60-07
*1
1 Schaffner
4038 FS5972-60-07
*1
1 Schaffner
4044 RTEN-5100 1 TDK
4060 RTEN-5100 1 TDK
*1 When you install an external EMC noise filter, change the terminals or use the junction terminal.
■ DC Link Chokes
To comply with EN 61000-3-2 drive models 2001 to 2006, and 4001 to 4004, install a DC link
choke when you use an internal or external EMC filter. Refer to Table 14.15 to select a DC link
choke.
Table 14.15 DC Link Chokes for Harmonic Suppression
Drive Model
DC Link Choke
Rating
2001 - 2006 5.4 A, 8 mA
4001 - 4004 3.2 A, 28 mA

YASKAWA GA50U Series Specifications

General

Category	DC Drives
Series	GA50U
Output Voltage	0 to Input Voltage
Cooling Method	Fan cooled
Control Method	Vector Control
Communication	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
