YL9120 UV/Vis Detector
Chapter 1. Introduction
The YL9120 UV/Vis Detector is the most sensitive and versatile absorbance detector available for HPLC.
It features dual wavelength capability, improved signal-to-noise performance, minimized drift and reduced
optical bandwidth. The YL9120 UV/Vis Detector is designed to provide higher performance in UV/VIS
detection for HPLC application such as development, analytical research and QA/QC.
1-1. Features of YL9120
1) Higher light intensity by Seya-Namioka optic structure and wide wavelength range
2) Lower drift by the blazed holographic concave grating
3) Better designed flow cell assembly by compensated RI effect
4) Improved baseline stability with heat exchange effect
L9120
5) Great Usability by mounting lamps and flow cell assembly on the front
6) Dual wavelength detection and spectrum scanning
1-2. Specifications
1) Wavelength Range : 190-900 nm
2) Data collection rate : up to 50Hz
3) Light Source : Deuterium arc lamp & tungsten lamp
4) 2-Order filter : Automatic filter switching
5) Bandwidth : 5.5 nm
6) Wavelength Accuracy : ±1 nm
7) Wavelength Precision : ±0.1nm
8) Linearity : >99.5% at 2.5 AU (acetone, 254nm)
-5
Abs/min , 254nm, dry cell
9) Noise level : <±0.5 X 10
-4
Abs/hour
10) Drift : <1 X 10
11) Dispersion element : Concave grating
12) Warm-up period : 1 hour
13) Flow Cell Design : Cone type
1
