YL Instruments YL9100 HPLC User Manual

YL9110 Quaternary Pump
Ready : It is displayed when the pump is ready.
Prime : It is displayed during prime/purge status.
Run : It is displayed during analysis.
Y
L9110
Fault : It is displayed if there is error on the pump.
Halt : It is displayed if the pump stops.
Diagnosis : It is displayed during self test.
4-4-3. Method Setup
In this window, edit time program table, and setup the pump status during idle state.
Click Options button to setup Max. and Min. pressure limit values to protect column and system. In this
window, you can type the name of solvent you will use.
On the below window, make a program for output signal of switch terminal on the rear side of YL9110
quaternary pump.
21
