YL Instruments YL9100 HPLC User Manual

YL9160 PDA Detector
13) Sampling Rate : Max. 50Hz 1~16 nm Spectral Bandwidth, Wide Spectral Range, Alternative
Spectral Function
15) GLP Compliance:
- Photometric Accuracy, Linearity, Noise Level, Drift
- System Check,
16) Analog Output : 2 channel (Replaceable Dual Wavelength Detector)
17) Valve Output : 2ch, Programmable Sampling (Fraction Collector Function Available )
18) Trigger Input : 2ch
19) Communication : TCP/IP
20) Simultaneous Data Channel : 8 or Full Scan
21) Filtering : Bessel, RC, Aver. 0.01~10Hz
[Selection of cells]
Microbore Analytical Semi-prep
Path length 10mm 5mm 3mm
Cell volume 13ul 6ul 5.3ul
Tube ID 0.007” 0.01” 0.02”
Cell pressure(psi) 1500 1500psi 1000psi
Flow contact
materials
PEEK, teflon,
Quartz
SS316, Teflon, Quartz
1-3. Optics Design
[Fig. 1] YL9160 PDA detector optics design
Optics design of YL9160 PDA detector is shown as [Fig. 1]. A deuterium lamp is used for ultraviolet
2
