App-4
IM 04L42B01-01E
Appendix2 TypesofDataFilesThattheDXCan
CreateandTheirApplication
This section explains the types of data files that the DX can create and their application.
DataType Extension Format DisplayMethod
*1
DX DAQ Application
Display data DAD Binary (undisclosed) Yes Yes Yes
*2, *3
DSD Yes Yes Yes
*2, *3
Event data DAE Binary (undisclosed) Yes Yes Yes
*2, *3
DSE Yes Yes Yes
*2, *3
Report data DAR Text (see appendix 3) - Yes Yes
xml XML spreadsheet - - Yes
Manual sampled data DAM Text (see appendix 3) - - Yes
Setup data PDL Binary (undisclosed) - - -
PEL - - -
Snapshot data PNG PNG (general format) - - Yes
Custom display setup data CDC Text - - -
Change settings log TXT Text - - Yes
*1
DX: DX main unit, DAQ: DAQSTANDARD, Application: Software application
*2
The data format can be converted on DAQSTANDARD and displayed on a software application
such as Microsoft Excel.
*3
The data can be retrieved from the DX using the communication function and displayed on a
software application.
To Next Page
