FileOutputExample
Below is a manual sample data example of channels 1, 2, 3, and 4.
YREC
Manual Sample Data Version 1.02.00
Model DX2000
Language Code shift-JIS
File Status Progress
Serial No. S5E701600
File Header
Ch CH001 CH002 CH003 CH004
Ch Id TI-101 OUT-102 FI-103 VA-204
Tag TI-101 OUT-102 FI-103 VA-204
Unit °C V m3/h %
2005/10/01 08:57:22 213.8 0.517 368.4 68.9
2005/10/01 08:57:28 208.6 0.494 363.0 68.1
Note
• Outputwhenerrordata,overrangedata,orcomputationoverflowdataisdetected
Channel Data Output
Measurement channels, Error (Space)
external input channel +over range (includes burnout detection) 99999
–over range (includes burnout detection) –99999
Computation channel Error 999999999
Positive computation overflow 999999999
(when the value exceeds 99999999)
Negative computation overflow –999999999
(when the value falls below –9999999)
The decimal place that was specified when the span for
the channel was specified applies to the output values. For
example, if the span setting of the channel is “200.0,” then
“999999999” is output when the value exceeds “9999999.9”
and “–999999999” is output when the value is below “–
999999.9.”
• Anewmanualsampleddatafileiscreatedinthefollowingcases.
• AmeasurementchannelischangedtoSkip from a range other than Skip.
• AmeasurementchannelischangedfromSkip to a range other than Skip.
• AcomputationorexternalinputchannelischangedfromOn to Off or Off to On.
• Theunitischanged.
