6.1 Signal Input Section
Item Specifications
Type Plug-in input unit
Number of slots 2
Maximum number of input
channels
8 channels (when 4-CH modules are installed in both slots) + instrument’s standard logic 16 bit
32 channels (when 16-CH modules are installed in both slots) + instrument’s standard logic 16 bit
240 channels (when the 720240 or 720241 modules are installed in both slots) + instrument’s
standard logic 16 bit
Memory size 200 Mpoints total (100 M per slot)
6.2 Recorder Mode Feature
Waveform Acquisition and Display
Item Specifications
Record conditions Preset time recording Records data for the specified time period from the start point
Continuous recording Records data for the specified time period before stopping
Trigger start Records data for the specified time period from a trigger
Trigger end Records data for the specified time period before a trigger
Acquisition mode Normal Normal waveform acquisition
Envelope Holds peak values at the maximum sample rate, regardless of the time
axis setting
Recording time 10 s to 50 days
Sampling interval 1 μs to 200 ms (1-2-5 series)
Action performed at the end
of recording
Screen capture data saving, waveform data saving, buzzer notification, mail transmission
SD recording (binary format) Sampling interval Depends on the number of used channels, 10 μs minimum (when 10
channels are in use)
1
Maximum number of
recorded points
1 Gpoint (with limitations depending on the used module)
Operation description Stores data in binary format in sync with acquisition
SD recording (ASCII format) Recording interval 1, 2, 5, 10, 15, 20, 30 s, 1, 2, 5, 10, 15, 20, 30, 60 min
Maximum recording size 2 GByte
Operation description Stores data in text format every specified recording interval
Event recording Records up to 100 events using the event input terminal
Display time range 1 ms to 10 s (1-2-5 steps), 20 s, 30 s, 40 s, 50 s, 60 s, 100 s, 200 s, 300 s
10 min to 60 min (10 min steps), 100 min
2 hour, 5 hour, 10 hour to 60 hour (10 hour steps), 80 hour, 100 hour
5 day, 10 day, 20 day, 30 day,
2
40day,
2
50 day
2
Zoom One window
Display format 1, 2, 3, 4, 5, 6, 8,12, 16 divided windows of TY display
Maximum number of
displayed traces
32 (standard logic 16 bit , including Math)
X-Y display Select X and Y axes from analog input waveforms and Math waveforms, up to two traces in one
window
1 May become 10 μs or more depending on the SD card
2 Only during real-time recording
Vertical Control
Item Specifications
Vertical axis setting Set with the measurement range
Channel on/off CHn, CHn_m, and Mathn can be turned on and off separately.
Vertical axis zooming By setting the scale using upper and lower limits
Linear scaling Can be set to Ax+B mode or P1-P2 mode (only for voltage, stress, and frequency)
Chapter 6 Specifications
