Appendix 5 Record Time and Sample Interval in
Recorder Mode
Memory Recording
Record Time Set from the Menu
With 4-CH Module Without 4-CH Module
Maximum Sample Minimum Sample Maximum Sample Minimum Sample
Minimum Value Maximum Value Rate Interval Rate Interval Rate Interval Rate Interval
– 10 s 1 MS 1 µs 100 S/s 10 ms 1 MS 1 µs 100 S/s 10 ms
11 s 20 s 500 kS 2 µs 50 S/s 20 ms 1 MS 1 µs 50 S/s 20 ms
21 s 30 s 200 kS 5 µs 20 S/s 50 ms 500 kS 2 µs 20 S/s 50 ms
31 s 40 s 200 kS 5 µs 20 S/s 50 ms 500 kS 2 µs 20 S/s 50 ms
41 s 50 s 200 kS 5 µs 20 S/s 50 ms 500 kS 2 µs 20 S/s 50 ms
51 s 60 s 100 kS 10 µs 10 S/s 100 ms 200 kS 5 µs 10 S/s 100 ms
61 s 100 s (1 min 40 s) 100 kS 10 µs 10 S/s 100 ms 200 kS 5 µs 10 S/s 100 ms
101 s (1 min 41 s) 200 s (3 min 20 s) 50 kS 20 µs 5 S/s 200 ms 100 kS 10 µs 5 S/s 200 ms
201 s (3 min 11 s) 300 s (5 min) 20 kS 50 µs 5 S/s 200 ms 50 kS 20 µs 5 S/s 200 ms
301 s (5 min 1 s) 600 s (10 min) 10 kS 100 µs 5 S/s 200 ms 20 kS 50 µs 5 S/s 200 ms
10 min 1 s 20 min* 5 kS 200 µs 5 S/s 200 ms 20 kS 50 µs 5 S/s 200 ms
20 min 1 s 30 min 5 kS 200 µs 5 S/s 200 ms 10 kS 100 µs 5 S/s 200 ms
30 min 1 s 40 min* 2 kS 500 µs 5 S/s 200 ms 10 kS 100 µs 5 S/s 200 ms
40 min 1 s 50 min 2 kS 500 µs 5 S/s 200 ms 5 kS 200 µs 5 S/s 200 ms
50 min 1s 60 min 2 kS 500 µs 5 S/s 200 ms 5 kS 200 µs 5 S/s 200 ms
61 min 100 min 1 kS 1 ms 5 S/s 200 ms 2 kS 500 µs 5 S/s 200 ms
101 min (1 hour 41 min) 120 min (2 hour) 1 kS 1 ms 5 S/s 200 ms 2 kS 500 µs 5 S/s 200 ms
121 min (2 hour 1 min) 300 min (5 hour) 500 S 2 ms 5 S/s 200 ms 1 kS 1 ms 5 S/s 200 ms
301 min (5 hour 1 min) 10 hour 200 S 5 ms 5 S/s 200 ms 500 S 2 ms 5 S/s 200 ms
10 hour 1 min 20 hour 100 S 10 ms 5 S/s 200 ms 200 S 5 ms 5 S/s 200 ms
20 hour 1 min 30 hour (1 day 6 hour)* 50 S 20 ms 5 S/s 200 ms 200 S 5 ms 5 S/s 200 ms
31 hour (1 day 7 hour) 40 hour (1 day 16 hour) 50 S 20 ms 5 S/s 200 ms 100 S 10 ms 5 S/s 200 ms
41 hour (1 day 17 hour) 50 hour (2 day 2 hour) 50 S 20 ms 5 S/s 200 ms 100 S 10 ms 5 S/s 200 ms
51 hour (2 day 3 hour) 60 hour (2 day 12 hour)* 20 S 50 ms 5 S/s 200 ms 100 S 10 ms 5 S/s 200 ms
61 hour (2 day 13 hour) 80 hour (3 day 8 hour) 20 S 50 ms 5 S/s 200 ms 50 S/s 20 ms 5 S/s 200 ms
81 hour (3 day 9 hour) 100 hour (4 day 4 hour) 20 S 50 ms 5 S/s 200 ms 50 S/s 20 ms 5 S/s 200 ms
101 hour (4 day 5 hour) 120 hour (5 day) 20 S 50 ms 5 S/s 200 ms 50 S/s 20 ms 5 S/s 200 ms
121 hour (5 day 1 hour) 10 day 10 S 100 ms 5 S/s 200 ms 20 S/s 50 ms 5 S/s 200 ms
10 day 1 hour 20 day 5 S 200 ms 5 S/s 200 ms 10 S/s 100 ms 5 S/s 200 ms
* There are sample intervals between the maximum sample interval and minimum sample interval that you cannot select.
