Event Input
Item Specifications
Connector type Screwless terminal block
Maximum rated voltage to
ground
Non-insulated (shared with the main unit GND)
Input level TTL (0 to 5 V) or contact input
COMP Output (Probe Compensation Signal Output Terminal)
Item Specifications
Output signal frequency 1 kHz ± 1%
Output amplitude 1 Vp-p ± 10%
GPS Interface
Item Specifications
Input connector 9-pin Mini DIN
Compatible GPS unit 720940/B8093YA (optional accessory)
6.11 Computer Interface
USB-PC Connection
Item Specifications
Connector type USB type B connector (mini)
Electrical and mechanical USB Rev. 2.0 compliant
Supported transfer modes HS (High Speed; 480 Mbps) and FS (Full Speed; 12 Mbps)
Supported protocols Functions as a device that conforms to one of the following two protocols.
USBTMC-USB488 (USB Test and Measurement Class Ver. 1.0)
1
Mass Storage Class Ver.1.1 (SD card only)
PC system requirements Windows 7, 8.1, 10
1 A separate driver is required.
Ethernet
Item Specifications
Connector type RJ-45 modular jack
Ports 1
Electrical and mechanical IEEE802.3 compliant
Transmission system Ethernet (100BASE-TX/10BASE-T)
Communication protocol TCP/IP
Supported services DHCP, DNS, SNTP client, SMTP client, FTP client, VXI-11, Web server
6.10 Auxiliary I/O Section
To Next Page
