YOKOGAWA DL350 Getting Started Guide

App-23
IM DL35 O -03EN
Appendix
1
2
3
4
5
6
App
Index
Appendix 6 Default Settings
Top
Menu
Item Value
CH1 to 4 (HS100M12 (720211))
Basic
V/Div
1
50 V/div
V Range
2
500 V
Coupling DC
BandWidth Full
Probe 10:1
Label Channel number
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
250.0 V
Lower
2
−250.0 V
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
Gain Adjustment 1.0000
DC Offset Cancel OFF
CH1 to 4 (HS10M12 (720250))
Basic
V/Div
1
50 V/div
V Range
2
500 V
Coupling DC
BandWidth Full
Probe 10:1
Label Channel number
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
250.0 V
Lower
2
−250.0 V
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
Gain Adjustment 1.0000
DC Offset Cancel OFF
CH1 to 4 (4CH 1M16 (720254))
Basic
V/Div
1
50 V/div
V Range
2
500 V
Coupling DC
BandWidth Full
Probe 10:1
Label
Sub channel number 1 CH<x>_1
Sub channel number 2 CH<x>_2
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
250.0 V
Lower
2
−250.0 V
Top
Menu
Item Value
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
Gain Adjustment 1.0000
DC Offset Cancel OFF
CH1 to 4 (HV (AAF, RMS)) (720268))
Basic
V/Div
1
5 V/div
V Range
2
50 V
Coupling DC
BandWidth Full
Label Channel number
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
25.000 V
Lower
2
−25.000 V
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
Gain Adjustment 1.0000
DC Offset Cancel OFF
CH1 to 4 (UNIVERSAL (701261), UNIVERSAL (AAF) (701262))
Basic
V/Div
1
5 V/div
V Range
2
50 V
Coupling DC
BandWidth Full
Label Channel number
Display
V Scale*1 DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
25.000 V
Lower
2
−25.000 V
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
CH1 to 4 (TEMP/HPV (701265), TEMP/HPV (LOW NOISE) (720266))
Basic
V/Div
1
5 V/div
V Range
2
50 V
Coupling DC
BandWidth Full
Label Channel number
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
250.0 V
Lower
2
−250.0 V
Invert OFF
Display Group 1, M
