Triggering Section
Item Specifications
Trigger mode Auto, normal (repeat), single, on-start
Selectable trigger level range 0 ± 10div
Trigger hysteresis When measuring voltage: Select from ±0.1 div, ±0.5 div, ±1 div.
When measuring temperature: Select from ±0.5°C, ±1.0°C, and ±2.0°C.
When measuring strain: Select from ±2.5%, ±12.5%, ±25% of range.
When measuring acceleration: Select from ±0.1 div, ±0.5 div, ±1 div of range.
When measuring frequency: Select from ±0.01 div, ±0.5 div, ±1 div of range.
CAN, LIN, SENT: Select from ±0.01 div, ±0.5 div, ±1 div of span.
Selectable trigger position range 0 to 100% (as a percentage of the display record length in 0.1% steps)
Selectable trigger delay range 0 to 10 s (in 10 ns steps)
Manual trigger Using a dedicated key
Simple trigger
Trigger source CHn, CHn_m (specified input channel, specified bit for logic), external, time
Trigger slope Rising, falling, rising and falling (rising, falling only for logic)
Clock trigger Date (year/month/day), time (hour/minute/second), time interval (10 seconds to 24 hours)
Enhanced trigger
Trigger source CHn, CHn_m (specified input channel, specified bit for logic), EXT
Trigger type OR, AND, Wave Window, Edge On A, Period, Pulse Width
OR Triggers on the OR of multiple trigger source edges (including window triggers)
AND Triggers on the AND of multiple state conditions (including window triggers)
Wave Window Power supply waveform monitoring trigger, number of target channels: 8 max.
Source frequency: 40 to 1 kHz, resolution: 1 Hz, operating sample rate: 10 k to 500 kS/s
Edge on A Triggers on the OR condition while the trigger A conditions are met (including window triggers)
Period Triggers when the period of condition T meets one of the following conditions.
T>Time: Longer than the specified time, time range: 0.02 μs to 10 s, resolution 0.01 μs
T>Time: Shorter than the specified time, time range: 0.02 μs to 10 s, resolution 0.01 μs
T1<T<T2: Within the specified time range, specified time T1: 0.02 μs to 9999999.99 μs,
T2: 0.03 μs to 10 s, resolution: 0.01μs
T<T1, T2<T: Outside the specified time range, specified time T1: 0.02 μs to 9999999.99 μs,
T2: 0.03 μs to 10 s, resolution: 0.01μs
Pulse Width Triggers when the time from when trigger B conditions are met meets one of the following
conditions.
B>Time: Time for trigger B conditions to not be met is longer than the specified time,
specified time: 0.01 μs to 10 s, resolution: 0.01μs
B<Time: Time for trigger B conditions to not be met is shorter than the specified time,
specified time: 0.01 μs to 10 s, resolution: 0.02μs
B Time Out: Time when trigger B conditions continue to be met is longer than the specified
time, specified time: 0.01 μs to 10 s, resolution: 0.01μs
B Between: Time when trigger B conditions continue to be met is within the specified time.
Triggers when the conditions are no longer met
Specified time T1: 0.01 μs to 9999999.99 μs, T2: 0.02 μs to 10 s, resolution: 0.01 μs
6.3 Scope Mode Features
