When the Record Length Is 1 G, 2 G, 4 G, 5 Gpoint
Time/div
Record length
1 G 2 G 4 G 5 G
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
1 µs – – – –
2 µs – – – –
5 µs – – – –
10 µs – – – –
20 µs – – – –
50 µs – – – –
100 µs – – – –
200 µs – – – –
500 µs – – – –
1 ms – – – –
2 ms – – – –
5 ms – – – –
10 ms – – – –
20 ms – – – –
50 ms – – – –
100 ms 1 M 1.0 M 1 M 1.0 M 1 M 1.0 M 1 M 1.0 M
200 ms 1 M 2.0 M 1 M 2.0 M 1 M 2.0 M 1 M 2.0 M
500 ms 1 M 5.0 M 1 M 5.0 M 1 M 5.0 M 1 M 5.0 M
1 s 1 M 10.0 M 1 M 10.0 M 1 M 10.0 M 1 M 10.0 M
2 s 1 M 20.0 M 1 M 20.0 M 1 M 20.0 M 1 M 20.0 M
3 s 1 M 30.0 M 1 M 30.0 M 1 M 30.0 M 1 M 30.0 M
4 s 1 M 40.0 M 1 M 40.0 M 1 M 40.0 M 1 M 40.0 M
5 s 1 M 50.0 M 1 M 50.0 M 1 M 50.0 M 1 M 50.0 M
6 s 1 M 60.0 M 1 M 60.0 M 1 M 60.0 M 1 M 60.0 M
10 s 1 M 100.0 M 1 M 100.0 M 1 M 100.0 M 1 M 100.0 M
20 s 1 M 200.0 M 1 M 200.0 M 1 M 200.0 M 1 M 200.0 M
30 s 1 M 300.0 M 1 M 300.0 M 1 M 300.0 M 1 M 300.0 M
1 min 1 M 600.0 M 1 M 600.0 M 1 M 600.0 M 1 M 600.0 M
2 min 500 k 600.0 M 1 M 1.2 G 1 M 1.2 G 1 M 1.2 G
3 min 500 k 900.0 M 1 M 1.8 G 1 M 1.8 G 1 M 1.8 G
4 min 200 k 480.0 M 500 k 1.2 G 1 M 2.4 G 1 M 2.4 G
5 min 200 k 600.0 M 500 k 1.5 G 1 M 3 G 1 M 3 G
6 min 200 k 720.0 M 500 k 1.8 G 1 M 3.6 G 1 M 3.6 G
10 min 100 k 600.0 M 200 k 1.2 G 500 k 3 G 500 k 3 G
12 min 100 k 720.0 M 200 k 1.44 G 500 k 3.6 G 500 k 3.6 G
30 min 50 k 900.0 M 100 k 1.8 G 200 k 3.6 G 200 k 3.6 G
1 hour 20 k 720.0 M 50 k 1.8 G 100 k 3.6 G 100 k 3.6 G
2 hour 10 k 720.0 M 20 k 1.44 G 50 k 3.6 G 50 k 3.6 G
3 hour 5 k 540.0 M 10 k 1.08 G 20 k 2.16 G 20 k 2.16 G
4 hour 5 k 720.0 M 10 k 1.44 G 20 k 2.88 G 20 k 2.88 G
5 hour 5 k 900.0 M 10 k 1.8 G 20 k 3.6 G 20 k 3.6 G
6 hour 2 k 432.0 M 5 k 1.08 G 10 k 2.16 G 20 k 4.32 G
8 hour 2 k 576.0 M 5 k 1.44 G 10 k 2.88 G 10 k 2.88 G
10 hour 2 k 720.0 M 5 k 1.8 G 10 k 3.6 G 10 k 3.6 G
12 hour 2 k 864.0 M 2 k 864.0 M 5 k 2.16 G 10 k 4.32 G
1 day 1 k 864.0 M 2 k 1.728 G 2 k 1.728 G 5 k 2.16 G
2 day 500 864.0 M 1 k 1.728 G 2 k 3.456 G 2 k 3.456 G
3 day 200 518.4 M
500 1.296 G 1 k 2.592 G 1 k 2.592 G
4 day 200 691.2 M 500 1.728 G 1 k 3.456 G 1 k 3.456 G
5 day 200 864.0 M 200 864.0 M 500 2.16 G 1 k 4.32 G
Appendix 1 Relationship between the Time Scale, Record Length, and Sample Rate
