5: Replacement Procedures
Spare Kit List
P1061942-001 Zebra ZXP Series 1 Card Printer Service Manual 105
5.5 Spare Kit List
The following table lists all the spare kits and upgrade kits, by kit number, and their associated
replacement procedure section(s).
KIT, # Description Section
P1031925-001 KIT, Upgrade, Ethernet PCBA 5.6.13
P1031925-007 KIT, MLB Single-sided 5.6.14
P1031925-009 KIT, CRYPTOGRAPHIC PCBA 5.6.27
P1031925-010 KIT, LCDisplay PCBA 5.6.7
P1031925-011 KIT, Mag Head 5.6.34
P1031925-012 KIT, Ribbon Sensor 5.6.2
P1031925-014 KIT, ATM Sensor 5.6.39
P1031925-015 KIT, Lid & Ribbon Encoder Sensors 5.6.28, 5.6.21
P1031925-018 KIT, Motor, Head Lift 5.6.25
P1031925-019 KIT, Ribbon Motor 5.6.26
P1031925-021 KIT, Linkage Springs 5.6.23, 5.6.24, 5.6.29, 5.6.30
P1031925-023 KIT, Ribbon Drive System 5.6.26
P1031925-025 KIT, Belts & O-Rings for Print Engine -
P1031925-026 KIT, Encoder Disk 5.6.22
P1031925-029 KIT, Cleaning Roller Assembly 5.6.37
P1031925-038 KIT, Latch for Feeder 5.6.10
P1031925-040 KIT, Ground Plate 5.6.15
P1031925-042 KIT, Cover for Feeder 5.6.6
P1031925-046 KIT, Feet for Printer 5.6.11
P1031925-047 KIT, Covers for Frame 5.6.21, 5.6.27
P1031925-048 KIT, Cables Electronics -
P1031925-049 KIT, Power Supply -
P1031925-050 KIT, Packaging -
P1031925-052 KIT, Miscellaneous Hardware -
P1031925-053 KIT, Feed Cover Sensor 5.6.9
P1031925-054 KIT, Sync Sensor 5.6.36
P1031925-055 KIT, Flipper Sensor 5.6.19
P1031925-070 KIT, Printhead 5.6.1
P1031925-071 KIT, Cooling Fans 5.6.8, 5.6.16
P1031925-072 KIT, Drive Linkage 5.6.23, 5.6.24, 5.6.29, 5.6.30
P1031925-073 KIT, Drive Gears & Camshaft 5.6.32
P1031925-074 KIT, Pressure Rollers 5.6.33
P1031925-076 Kit Flipper Assembly 5.6.19
P1031925-100 Kit Upgrade Manual Front Feed 5.6.20
P1031925-137 KIT, Button For Door 5.6.5
P1031925-141 KIT, Top Cover And Badge 5.6.5
P1031925-143 KIT, Side Panels Bezels 5.6.3, 5.6.4, 5.6.12, 5.6.20
P1031925-217 KIT, Motor Card Drive 5.6.31
P1031925-224 KIT, Drive System 5.6.24
P1031925-228 Kit Platens For Print Engine 5.6.38, 5.6.40
P1031925-230 KIT, Feeder Assembly 5.6.18
P1031925-233 KIT, Carrier And Drive For Flipper 5.6.19
P1031925-235 KIT, Inner Top Assembly 5.6.17
P1031925-244 KIT, Output Hopper Non-Encode 5.6.20
