220 Zebra ZXP Series 1 Card Printer Service Manual P1061942-001
E: Magnetic Encoder Option
Encoder Settings (Driver)
The Encoder Settings dialog box is used for setting various Magnetic Encoder parameters.
This feature is not enabled if the printer does not have the magnetic encoder option.; see
Encoding Tab on page 65 for details.
Media Loading Orientation
When loading cards with magnetic stripes into the card feeder, please ensure that the magnetic
stripe is facing the left side of the printer, and closest to the bottom edge of the card feeder; see
Loading Cards on page 71 for details.
Magnetic Encoder Cleaning
Use the standard cleaning card process as described in Section 6, Preventive Maintenance.
This cleans the most important parts of the printer; including the Printhead, Transport Roller,
and Magnetic Stripe Encoder.
Caution • ONLY USE cards that comply with ISO 7810 & 7811 standards for magnetic
stripe cards. The magnetic stripe must be flush to the surface of the card to work properly.
Never use cards which have taped-on magnetic stripes.
Note • Zebra-approved HiCo & LoCo PVC cards are available; see http://www.zebra.com/
supplies for details.
