Operation Manual / 4 Product description / A130-H.. - A140-H
2 Removing and Installing / 2.2 Removing the turbocharger
© Copyright 2017 ABB. All rights reserved. HZTL4030_EN Revision D May 2017
2.2.3 Positioning the turbocharger for storage
WARNING
Risk of tipping
If the turbocharger is not positioned stably, it may tip over. This can result in
serious personal injury.
u Place the turbocharger on a clean, level support.
u Secure the turbocharger to prevent it from tipping over by using wooden
beams and wedges and by taking the centre of gravity into account.
Fig.8: Putting down the turbocharger
u Remove turbocharger from engine support, set it down properly in an appropriate place
and secure it.
u Close or cover the openings of the turbocharger and support.
Page 12 / 91
