Parameters 107
28.23 Constant frequency sel2 [0]Always off, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
28.72 Freq acceleration time 1 0.000 … 1800.000 s, 3s
28.73 Freq deceleration time 1 0.000 … 1800.000 s, 3s
28.26 Constant frequency 1 -500.00 … 500.00Hz, 5Hz
28.27 Constant frequency 2 -500.00 … 500.00Hz, 10Hz
28.28 Constant frequency 3 -500.00 … 500.00Hz, 15Hz
Group 30 Limits
30.11 Minimum speed -30000.00 … 30000.00rpm, -1500.00rpm
30.12 Maximum speed -30000.00 … 30000.00rpm, 1500.00rpm
30.13 Minimum frequency -500 … 500 Hz, -50Hz
30.14 Maximum frequency -500 … 500 Hz, 50Hz
30.17 Maximum current depend on rating
Group 31 Fault functions
31.11 Fault reset selection [0]not used, [2]DI1, [3]DI2, [4]DI3, [5]DI4, [6]DI5
Group 40 Process PID set 1
40.07 Process PID operation mode [0]OFF, [1]ON, [2]ON when drive running
40.08 Set 1 feedback 1 source [8]AI1 percent, [9]AI2 percent
40.16 Set 1 setpoint 1 source [2]Internal setpoint, [11]AI1 percent, [12]AI2 percent
40.24 Set 1 internal setpoint 0 -200000.00 … 200000.00, 0
40.31 Set 1 deviation inversion [0]Not inverted (Ref - Fbk), [1]Inverted (Fbk - Ref)
40.32 Set 1 gain 0.01 … 100.00, 1
40.33 Set 1 integration time 0.0 … 9999.0 s, 60s
Group 45 Energy efficiency
45.11 Energy optimizer [0]Disable, [1]Enable
Group 58 Embedded fieldbus
58.01 Protocol enable [0]None, [1]ModbusRTU
58.03 Node address 0 … 255, 1
58.04 Baud rate [1]4800, [2]9600, [3]19200, [4]38400, [5]57600, [6]76800,
[7]115200
58.05 Parity [0]8 NONE 1
, [1]8 NONE 2, [2]8 EVEN 1, [3]8 ODD 1
58.06 Communication control [0]Enabled, [1]Refresh settings
58.14 Communication loss action [0]No action, [1]Fault, [2]Last speed, [5]Warning
Par. No. Par. Name Settings/Range (default value on bold)
ACS180 FW.book Page 107 Tuesday, March 9, 2021 2:25 PM
