ABB ACS180 User Manual

324 Additional parameter data
46.03 Torque scaling Real 0.1…1000.0 % 10 = 1%
46.04 Power scaling Real 0.10…30000.00 - 10 = 1 unit
46.05 Current scaling Real 0…30000 A 1 = 1 A
46.06 Speed ref zero scaling Real 0.00 … 30000.00 rpm 100 = 1 rpm
46.07 Frequency ref zero scaling Real 0.00 … 1000.00 Hz 100 = 1 Hz
46.11 Filter time motor speed Real 2…20000 ms 1 = 1 ms
46.12 Filter time output frequency Real 2…20000 ms 1 = 1 ms
46.13 Filter time motor torque Real 2…20000 ms 1 = 1 ms
46.14 Filter time power Real 2…20000 ms 1 = 1 ms
46.21 At speed hysteresis Real 0.00…30000.00 rpm 100 = 1 rpm
46.22 At frequency hysteresis Real 0.00…1000.00 Hz 100 = 1 Hz
46.23 At torque hysteresis Real 0.00…300.00 % 1 = 1%
46.31 Above speed limit Real 0.00…30000.00 rpm 100 = 1 rpm
46.32 Above frequency limit Real 0.00…1000.00 Hz 100 = 1 Hz
46.33 Above torque limit Real 0.0…1600.0 % 10 = 1%
46.41 kWh pulse scaling Real 0.001…1000.000 kWh 1000 = 1 kWh
47 Data storage
47.01 Data storage 1 real32 Real -2147483.008…
2147483.008
- 1000 = 1
47.02 Data storage 2 real32 Real -2147483.008…
2147483.008
- 1000 = 1
47.03 Data storage 3 real32 Real -2147483.008…
2147483.008
- 1000 = 1
47.04 Data storage 4 real32 Real -2147483.008…
2147483.008
- 1000 = 1
47.11 Data storage 1 int32 Real -2147483648…
2147483647
-1 = 1
47.12 Data storage 2 int32 Real -2147483648…
2147483647
-1 = 1
47.13 Data storage 3 int32 Real -2147483648…
2147483647
-1 = 1
47.14 Data storage 4 int32 Real -2147483648…
2147483647
-1 = 1
47.21 Data storage 1 int16 Real -32768…32767 - 1 = 1
47.22 Data storage 2 int16 Real -32768…32767 - 1 = 1
47.23 Data storage 3 int16 Real -32768…32767 - 1 = 1
47.24 Data storage 4 int16 Real -32768…32767 - 1 = 1
49 Panel port communication
49.01 Node ID number Real 1…32 - 1 = 1
49.03 Baud rate List 1…5 - 1 = 1
49.04 Communication loss time Real 0.3…3000.0 s 10 = 1 s
49.05 Communication loss action List 0…3 - 1 = 1
49.06 Refresh settings List 0…1 - 1 = 1
49.19 Basic panel home view 1 - -
No. Name Type Range Unit FbEq32
ACS180 FW.book Page 324 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
