ABB ACS180 User Manual

Parameters 297
Differences in the default values between 50 Hz and 60 Hz
supply frequency settings
Parameter 95.20 HW options word 1 bit 0 changes the drive parameter default values
according to the supply frequency, 50 Hz or 60 Hz. The bit is set according to the
market before the drive is delivered.
If you need to change from 50 Hz to 60 Hz, or vice versa, change the value of the bit
and then do a complete reset to the drive (96.06 Parameter restore). After that you
have to reselect the macro to be used.
The table below shows the parameters whose default values depend on the supply
frequency setting. The supply frequency setting, with the type designation of the
drive, also affects group 99 Motor data parameter values (not listed in the table).
No Name 95.20 HW options word 1 bit 0
Supply frequency 60 Hz =
50 Hz
95.20 HW options word 1
bit 0 Supply frequency 60 Hz =
60 Hz
11.45 Freq in 1 at scaled max 1500.000 1800.000
12.20 AI1 scaled at AI1 max 1500.000 1800.000
13.18 AO1 source max 1500.0 1800.0
22.26 Constant speed 1 300.00 rpm 360.00 rpm
22.27 Constant speed 2 600.00 rpm 720.00 rpm
22.28 Constant speed 3 900 .00 rpm 1080.00 rpm
22.29 Constant speed 4 1200.00 rpm 1440.00 rpm
22.30 Constant speed 5 1500.00 rpm 1800.00 rpm
22.31 Constant speed 6 2400.00 rpm 2880.00 rpm
22.32 Constant speed 7 3000.00 rpm 3600.00 rpm
28.26 Constant frequency 1 5.00 Hz 6.00 Hz
28.27 Constant frequency 2 10.00 Hz 12.00 Hz
28.28 Constant frequency 3 15.00 Hz 18.00 Hz
28.29 Constant frequency 4 20.00 Hz 24.00 Hz
28.30 Constant frequency 5 25.00 Hz 30.00 Hz
28.31 Constant frequency 6 40.00 Hz 48.00 Hz
28.32 Constant frequency 7 50.00 Hz 60.00 Hz
30.11 Minimum speed -1500.00 rpm -1800.00 rpm
30.12 Maximum speed 1500.00 rpm 1800.00 rpm
30.13 Minimum frequency -50.00 Hz -60.00 Hz
30.14 Maximum frequency 50.00 Hz 60.00 Hz
31.26 Stall speed limit 150.00 rpm 180.00 rpm
31.27 Stall frequency limit 15.00 Hz 18.00 Hz
31.30 Overspeed trip margin 500.00 rpm 500.00 rpm
46.01 Speed scaling 1500.00 rpm 1800.00 rpm
46.02 Frequency scaling 50.00 Hz 60.00 Hz
ACS180 FW.book Page 297 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
