Parameters 139
AO has automatic scaling. Every time the source for the AO is changed, the scaling range is
changed accordingly. User given minimum and maximum values override the automatic values.
-32768.0…32767.0 Real signal value corresponding to minimum AO1 output
value.
1 = 1
13.18 AO1 source max Defines the real maximum value of the signal (selected by
parameter 13.12 AO1 source) that corresponds to the
maximum required AO1 output value (defined by
parameter 13.20 AO1 out at AO1 src max). See
parameter 13.17 AO1 source min.
50.0
-32768.0…32767.0 Real signal value corresponding to maximum AO1 output
value.
1 = 1
13.19 AO1 out at AO1 src
min
Defines the minimum output value for analog output AO1.
See also drawing at parameter 13.17 AO1 source min.
0.000 mA
0.000…22.00 mA
0.000…11.000 V
Minimum AO1 output value. 1000 = 1 mA
No. Name/Value Description Default
FbEq 16
13.12 AO1 source,
13.22 AO2 source
13.17 AO1 source min,
13.27 AO2 source min
13.18 AO1 source max,
13.28 AO2 source max
0Zero N/A (Output is constant zero.)
1 Motor speed used 0 46.01 Speed scaling
3 Output frequency 0 46.02 Frequency scaling
4 Motor current 0 Max. value of 30.17 Maximum
current
5 Motor current % of motor
nom
0% 100%
6 Motor torque 0 46.03 Torque scaling
7 DC voltage Min. value of 01.11 DC
voltage
Max. value of 01.11 DC
voltage
8 Output power 0 46.04 Power scaling
10 Speed ref ramp in 0 46.01 Speed scaling
11 Speed ref ramp out 0 46.01 Speed scaling
12 Speed ref used 0 46.01 Speed scaling
14 Freq ref used 0 46.02 Frequency scaling
16 Process PID out Min. value of 40.01 Process
PID output actual
Max. value of 40.01 Process
PID output actual
20 Temp sensor 1 excitation N/A (Analog output is not scaled; it is determined by the
sensor’s triggering voltage.)
21 Temp sensor 2 excitation
26 Abs motor speed used
0 46.01 Speed scaling
27 Abs motor speed % 0 46.01 Speed scaling
28 Abs output frequency 0 46.02 Frequency scaling
30 Abs motor torque 0 46.03 Torque scaling
31 Abs output power 0 46.04 Power scaling
32 Abs motor shaft power 0 46.04 Power scaling
33 External PID1 out Min. value of 71.01 External
PID act value
Max. value of 71.01 External
PID act value
Other Min. value of the selected
parameter
Max. value of the selected
parameter
ACS180 FW.book Page 139 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
