ABB ACS180 User Manual

Parameters 197
28.92 Frequency ref act 3 Displays the frequency reference after the function
applied by parameter 28.13 Ext1 frequency function (if
any), and after selection (19.11 Ext1/Ext2 selection ). See
the control chain diagram on page 376.
This parameter is read-only.
0.00 Hz
-500.00…500.00 Hz Frequency reference after selection. See par.
46.02
28.96 Frequency ref act 7 Displays the frequency reference after application of
constant frequencies, control panel reference, etc. See
the control chain diagram on page 376.
This parameter is read-only.
0.00 Hz
-500.00…500.00 Hz Frequency reference 7. See par.
46.02
28.97 Frequency ref
unlimited
Displays the frequency reference after application of
critical frequencies, but before ramping and limiting. See
the control chain diagram on page 376.
This parameter is read-only.
0.00 Hz
-500.00…500.00 Hz Frequency reference before ramping and limiting. See par.
46.02
30
30 Limits
Drive operation limits.
30.01 Limit word 1 Displays limit word 1.
This parameter is read-only.
-
0000h…FFFFh Limit word 1. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Torq lim 1 = Drive torque is being limited by the motor control (undervoltage
control, current control, load angle control or pull-out control), or by the
torque limits defined by parameters.
1…2 Reserved
3 Torq ref max 1 = Torque reference is being limited by 26.09 Maximum torque ref or
30.20 Maximum torque 1
4 Torq ref min 1 = Torque reference is being limited by 26.08 Minimum torque ref or
30.19 Minimum torque 1
5 Tlim max speed 1 = Torque reference is being limited by the rush control because of
maximum speed limit (30.12 Maximum speed)
6 Tlim min speed 1 = Torque reference is being limited by the rush control because of
minimum speed limit (30.11 Minimum speed)
7 Max speed ref lim 1 = Speed reference is being limited by 30.12 Maximum speed
8 Min speed ref lim 1 = Speed reference is being limited by 30.11 Minimum speed
9 Max freq ref lim 1 = Frequency reference is being limited by 30.14 Maximum frequency
10 Min freq ref lim 1 = Frequency reference is being limited by 30.13 Minimum frequency
11…15 Reserved
ACS180 FW.book Page 197 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
