19.17 Local control disable Enables/disables local control (start and stop buttons on
the control panel, and the local controls on the PC tool).
WARNING! Before disabling local control, ensure
that the control panel is not needed for stopping
the drive.
No
No Local control enabled. 0
Yes Local control disabled. 1
20
20 Start/stop/direction
Start/stop/direction and run/start/jog enable signal source
selection; positive/negative reference enable signal
source selection.
For information on control locations, see section Local
and external control locations (page 44).
20.01 Ext1 commands Selects the source of start, stop and direction commands
for external control location 1 (EXT1).
See also parameters 20.02…20.05. See parameter 20.21
for the determination of the actual direction.
In1 Start; In2
Dir
Not selected No start or stop command sources selected. 0
In1 Start The source of the start and stop commands is selected by
parameter 20.03 Ext1 in1 source. The state transitions of
the source bits are interpreted as follows:
1
In1 Start; In2 Dir The source selected by 20.03 Ext1 in1 source is the start
signal; the source selected by 20.04 Ext1 in2 source
determines the direction. The state transitions of the
source bits are interpreted as follows:
2
In1 Start fwd; In2 Start
rev
The source selected by 20.03 Ext1 in1 source is the
forward start signal; the source selected by 20.04 Ext1 in2
source is the reverse start signal. The state transitions of
the source bits are interpreted as follows:
3
No. Name/Value Description Default
FbEq 16
State of source 1 (20.03) Command
0
-
> 1 (20.02 = Edge)
1 (20.02 = Level)
Start
0Stop
State of source 1
(20.03)
State of source 2
(20.04)
Command
0AnyStop
0
-
> 1 (20.02 = Edge)
1 (20.02 = Level)
0 Start forward
1 Start reverse
State of source 1
(20.03)
State of source 2
(20.04)
Command
00Stop
0
-
> 1 (20.02 = Edge)
1 (20.02 = Level)
0 Start forward
0
0
-
> 1 (20.02 = Edge)
1 (20.02 = Level)
Start reverse
11Stop
ACS180 FW.book Page 142 Tuesday, March 9, 2021 2:25 PM
