314 Additional parameter data
28.72 Freq acceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
28.73 Freq deceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
28.74 Freq acceleration time 2 Real 0.000…1800.000 s 1000 = 1 s
28.75 Freq deceleration time 2 Real 0.000…1800.000 s 1000 = 1 s
28.76 Freq ramp in zero source Binary src --1 = 1
28.82 Shape time 1 Real 0.000…1800.000 s 1000 = 1 s
28.83 Shape time 2 Real 0.000…1800.000 s 1000 = 1 s
28.92 Frequency ref act 3 Real -500.00…500.00 Hz 100 = 1 Hz
28.96 Frequency ref act 7 Real -500.00…500.00 Hz 100 = 1 Hz
28.97 Frequency ref unlimited Real -500.00 … 500.00 Hz 100 = 1 Hz
30 Limits
30.01 Limit word 1 PB 0000h…FFFFh - 1 = 1
30.02 Torque limit status PB 0000h…FFFFh - 1 = 1
30.11 Minimum speed Real -30000.00…30000.00 rpm 100 = 1 rpm
30.12 Maximum speed Real -30000.00…30000.00 rpm 100 = 1 rpm
30.13 Minimum frequency Real -500.00…500.00 Hz 100 = 1 Hz
30.14 Maximum frequency Real -500.00…500.00 Hz 100 = 1 Hz
30.17 Maximum current Real 0.00…30000.00 A 100 = 1 A
30.18 Torq lim sel Binary src --1 = 1
30.19 Minimum torque 1 Real -1600.0…0.0 % 10 = 1%
30.20 Maximum torque 1 Real 0.0…1600.0 % 10 = 1%
30.21 Min torque 2 source Analog src --1 = 1
30.22 Max torque 2 source Analog src --1 = 1
30.23 Minimum torque 2 Real -1600.0…0.0 % 10 = 1%
30.24 Maximum torque 2 Real 0.0…1600.0 % 10 = 1%
30.26 Power motoring limit Real 0.00…600.00 % 100 = 1%
30.27 Power generating limit Real -600.00…0.00 % 100 = 1%
30.30 Overvoltage control List 0…1 - 1 = 1
30.31 Undervoltage control List 0…1 - 1 = 1
30.35 Thermal current limitation List 0...1 - 1 = 1
30.36 Speed limit selection Binary src --1 = 1
30.37 Min speed source Analog src --1 = 1
30.38 Max speed source Analog src --1 = 1
31 Fault functions
31.01 External event 1 source Binary src --1 = 1
31.02 External event 1 type List 0…1 - 1 = 1
31.03 External event 2 source Binary src --1 = 1
31.04 External event 2 type List 0…1 - 1 = 1
31.05 External event 3 source Binary src --1 = 1
31.06 External event 3 type List 0…1 - 1 = 1
31.07 External event 4 source Binary src --1 = 1
No. Name Type Range Unit FbEq32
ACS180 FW.book Page 314 Tuesday, March 9, 2021 2:25 PM
