ABB ACS180 User Manual

316 Additional parameter data
32.20 Supervision 2 high Real -21474830.00…
21474830.00
- 100 = 1
32.21 Supervision 2 hysteresis Real 0.00…100000.00 - 100 = 1
32.25 Supervision 3 function List 0…7 - 1 = 1
32.26 Supervision 3 action List 0…2 - 1 = 1
32.27 Supervision 3 signal Analog src --1 = 1
32.28 Supervision 3 filter time Real 0.000…30.000 s 1000 = 1 s
32.29 Supervision 3 low Real -21474830.00…
21474830.00
- 100 = 1
32.30 Supervision 3 high Real -21474830.00…
21474830.00
- 100 = 1
32.31 Supervision 3 hysteresis Real 0.00…100000.00 - 100 = 1
32.35 Supervision 4 function List 0…7 - 1 = 1
32.36 Supervision 4 action List 0…2 - 1 = 1
32.37 Supervision 4 signal Analog src --1 = 1
32.38 Supervision 4 filter time Real 0.000…30.000 s 1000 = 1 s
32.39 Supervision 4 low Real -21474830.00…
21474830.00
- 100 = 1
32.40 Supervision 4 high Real -21474830.00…
21474830.00
- 100 = 1
32.41 Supervision 4 hysteresis Real 0.00…100000.00 - 100 = 1
32.45 Supervision 5 function List 0…7 - 1 = 1
32.46 Supervision 5 action List 0…2 - 1 = 1
32.47 Supervision 5 signal Analog src --1 = 1
32.48 Supervision 5 filter time Real 0.000…30.000 s 1000 = 1 s
32.49 Supervision 5 low Real -21474830.00…
21474830.00
- 100 = 1
32.50 Supervision 5 high Real -21474830.00…
21474830.00
- 100 = 1
32.51 Supervision 5 hysteresis Real 0.00…100000.00 - 100 = 1
32.55 Supervision 6 function List 0…7 - 1 = 1
32.56 Supervision 6 action List 0…2 - 1 = 1
32.57 Supervision 6 signal Analog src --1 = 1
32.58 Supervision 6 filter time Real 0.000…30.000 s 1000 = 1 s
32.59 Supervision 6 low Real -21474830.00…
21474830.00
- 100 = 1
32.60 Supervision 6 high
Real -21474830.00…
21474830.00
- 100 = 1
32.61 Supervision 6 hysteresis Real 0.00…100000.00 - 100 = 1
35 Motor thermal protection
35.01 Motor estimated temperature Real -60…1000 °C °C or °F 1 = 1°
35.02 Measured temperature 1 Real -60…5000 °C °C, °F or
ohm
1 = 1 unit
35.05 Motor overload level Real 0.0...300.0% % 10 = 1%
No. Name Type Range Unit FbEq32
ACS180 FW.book Page 316 Tuesday, March 9, 2021 2:25 PM
