Additional parameter data 309
13.15 AO1 unit selection List 2, 10 - 1 = 1
13.16 AO1 filter time Real 0.000…30.000 s 1000 = 1 s
13.17 AO1 source min Real -32768.0…32767.0 - 10 = 1
13.18 AO1 source max Real -32768.0…32767.0 - 10 = 1
13.19 AO1 out at AO1 src min Real 0.000…22.000 mA 1000 = 1 mA
13.20 AO1 out at AO1 src max Real 0.000…22.000 mA 1000 = 1 mA
13.91 AO1 data storage Real -327.68 … 327.67 - 100 = 1
19 Operation mode
19.01 Actual operation mode List 1…5, 10, 20 - 1 = 1
19.11 Ext1/Ext2 selection Binary src --1 = 1
19.12 Ext1 control mode List 1…5 - 1 = 1
19.14 Ext2 control mode List 1…5 - 1 = 1
19.16 Local control mode List 0…1 - 1 = 1
19.17 Local control disable List 0…1 - 1 = 1
20 Start/stop/direction
20.01 Ext1 commands List 0…6, 11…12, 14...16,
21...23
-1 = 1
20.02 Ext1 start trigger type List 0…1 - 1 = 1
20.03 Ext1 in1 source Binary src --1 = 1
20.04 Ext1 in2 source Binary src --1 = 1
20.05 Ext1 in3 source Binary src --1 = 1
20.06 Ext2 commands List 0…6, 11…12, 14, 21...23 - 1 = 1
20.07 Ext2 start trigger type List 0…1 - 1 = 1
20.08 Ext2 in1 source Binary src --1 = 1
20.09 Ext2 in2 source Binary src --1 = 1
20.10 Ext2 in3 source Binary src --1 = 1
20.11 Run enable stop mode List 0…2 - 1 = 1
20.12 Run enable 1 source Binary src --1 = 1
20.19 Enable start command Binary src --1 = 1
20.21 Direction List 0…2 - 1 = 1
20.22 Enable to rotate Binary src --1 = 1
20.25 Jogging enable Binary src --1 = 1
20.26 Jogging 1 start source Binary src --1 = 1
20.27 Jogging 2 start source Binary src --1 = 1
20.30 Enable signals warning
function
PB 0000h…FFFFh - 1 = 1
21 Start/stop mode
21.01 Start mode List 0…2 - 1 = 1
21.02 Magnetization time Real 0…10000 ms 1 = 1 ms
21.03 Stop mode List 0…2 - 1 = 1
21.04 Emergency stop mode List 0…3 - 1 = 1
No. Name Type Range Unit FbEq32
ACS180 FW.book Page 309 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
