Parameters 113

04.40 Event word 1 Shows the user-defined event word. This word collects the

status of the events (warnings, faults or pure events)

selected by parameters 04.41…04.71.

This parameter is read-only.

0000h…FFFFh 1 = 1

04.41 Event word 1 bit 0

code

Selects the hexadecimal code of an event (warning, fault

or pure event) whose status is shown as bit 0 of

parameter 04.40. See chapterFault tracing (page 331) for

the event codes.

0X2310h

0000h…FFFFh Code of event. 1 = 1

04.43 Event word 1 bit 1

code

Selects the hexadecimal code of an event (warning, fault

or pure event) whose status is shown as bit 1 of

parameter 04.40. See chapter Fault tracing (page 331) for

the event codes.

0X3210h

0000h…FFFFh Code of event. 1 = 1

04.45 Event word 1 bit 2

code

… 0X4310h

04.47 Event word 1 bit 3

code

… 0X2340h

04.49 Event word 1 bit 4

code

… 0X0000h

04.51 Event word 1 bit 5

code

… 0X3220h

04.53 Event word 1 bit 6

code

… 0X80A0h

04.55 Event word 1 bit 7

code

… 0X0000h

04.57 Event word 1 bit 8

code

… 0X7122h

04.59 Event word 1 bit 9

code

… 0X7081h

04.61 Event word 1 bit 10

code

… 0XFF61h

04.63 Event word 1 bit 11

code

… 0X7121h

04.65 Event word 1 bit 12

code

…0X4110h

04.67 Event word 1 bit 13

code

… 0X9081h

04.69 Event word 1 bit 14

code

… 0X9082h

No. Name/Value Description Default

FbEq 16

Bit Name Description

0 User bit 0 1 = Event selected by parameter 04.41 is active.

1 User bit 1 1 = Event selected by parameter 04.43 is active.

…… …

15 User bit 15 1 = Event selected by parameter 04.71 is active.
