ABB ACS180 User Manual

120 Parameters
06.18 Start inhibit status
word
Start inhibit status word. This word specifies the source of
the inhibiting signal that is preventing the drive from
starting.
The conditions marked with an asterisk (*) only require
that the start command is cycled to reset the inhibition. In
all other instances, the inhibiting condition must be
removed first.
See also parameter 06.16 Drive status word 1, bit 1.
This parameter is read-only.
-
0000h…FFFFh Start inhibit status word. 1 = 1
06.19 Speed control status
word
Speed control status word.
This parameter is read-only.
--
0000h…FFFFh Speed control status word. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Not ready run 1 = DC voltage is missing or drive has not been parametrized
correctly. Check the parameters in groups 95 and 99.
1 Ctrl location changed * 1 = Control location has changed
2 SSW inhibit 1 = Control program is keeping itself in inhibited state
3 Fault reset * 1 = A fault has been reset
4 Lost start enable 1 = Start enable signal missing
5 Lost run enable 1 = Run enable signal missing
6 Reserved
7 STO 1 = Safe torque off function active
8 Current calibration
ended
* 1 = Current calibration routine has finished
9 ID run ended * 1 = Motor identification run has finished
10 Reserved -
11 Em Off1 1 = Emergency stop signal (mode off1)
12 Em Off2 1 = Emergency stop signal (mode off2)
13 Em Off3 1 = Emergency stop signal (mode off3)
14 Auto reset inhibit 1 = The autoreset function is inhibiting operation
15 Jogging active 1 = The jogging enable signal is inhibiting operation
Bit Name Description
0 Zero speed
1 = Drive has been running below zero speed limit (par. 21.06)
for a time defined by parameter 21.07 Zero speed delay
1Forward
1 = Drive is running in forward direction above zero speed limit
(par. 21.06)
2 Reverse
1 = Drive is running in reverse direction above zero speed limit
(par. 21.06)
3 Out of window Speed out of speed window
4 Internal speed feedback Estimate used for motor control
7
Any constant speed
request
1 = A constant speed or frequency has been selected; see par.
06.20 below.
10...15 Reserved
ACS180 FW.book Page 120 Tuesday, March 9, 2021 2:25 PM
