ABB ACS180 User Manual

184 Parameters
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 4
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 5
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 6
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 7
Other [bit] Source selection (see Terms and abbreviations). -
26.17 Torque ref filter time Defines a low-pass filter time constant for the torque
reference.
0.000 s
0.000…30.000 s Filter time constant for torque reference. 1000 = 1 s
26.18 Torque ramp up time Defines the torque reference ramp-up time, ie. the time for
the reference to increase from zero to nominal motor
torque.
0.000 s
0.000…60.000 s Torque reference ramp-up time. 100 = 1 s
26.19 Torque ramp down
time
Defines the torque reference ramp-down time, ie. the time
for the reference to decrease from nominal motor torque
to zero.
0.000 s
0.000…60.000 s Torque reference ramp-down time. 100 = 1 s
26.20 Torque reversal Inverts the torque reference or selects the source for the
inversion signal.
Torque reversal is located in the torque reference chain
after torque reference act 3 signal, so the inversion is
visible in torque reference act 4 signal.
Always off
Always off Torque reference is not inverted. 0
Always on Torque reference is inverted. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status.24
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see Terms and abbreviations). -
26.70 Torque reference act 1 Displays the value of torque reference source 1 (selected
by parameter 26.11 Torque ref1 source
). See the control
chain diagram on page 383.
This parameter is read-only.
-
-1600.0…1600.0% Value of torque reference source 1. See par.
46.03
No. Name/Value Description Default
FbEq 16
ACS180 FW.book Page 184 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
