290 Parameters
98.02 Rs user Defines the stator resistance R
S
of the motor model.
With a star-connected motor, R
S
is the resistance of one
winding. With a delta-connected motor, R
S
is one-third of
the resistance of one winding.
0.00000 p.u.
0.00000…0.50000
p.u.
Stator resistance in per unit. -
98.03 Rr user Defines the rotor resistance R
R
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00000 p.u.
0.00000…0.50000
p.u.
Rotor resistance in per unit. -
98.04 Lm user Defines the main inductance L
M
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00000 p.u.
0.00000… 10.00000
p.u.
Main inductance in per unit. -
98.05 SigmaL user Defines the leakage inductance
L
S
.
Note: This parameter is valid only for asynchronous
motors.
0.00000 p.u.
0.00000…1.00000
p.u.
Leakage inductance in per unit. -
98.06 Ld user Defines the direct axis (synchronous) inductance.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 p.u.
0.00000 … 10.00000
p.u
Direct axis inductance in per unit. -
98.07 Lq user Defines the quadrature axis (synchronous) inductance.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 p.u.
0.00000 … 10.00000
p.u
Quadrature axis inductance in per unit. -
98.08 PM flux user Defines the permanent magnet flux.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 p.u.
0.00000 … 2.00000
p.u
Permanent magnet flux in per unit. -
98.09 Rs user SI Defines the stator resistance R
S
of the motor model. 0.00000 ohm
0.00000…
100.00000 ohm
Stator resistance. -
98.10 Rs user SI Defines the rotor resistance R
R
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00000 ohm
0.00000…
100.00000 ohm
Rotor resistance. -
98.11 Lm user SI Defines the main inductance L
M
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00 mH
0.00…100000.00 mH Main inductance. 1 = 10000
mH
No. Name/Value Description Default
FbEq 16
ACS180 FW.book Page 290 Tuesday, March 9, 2021 2:25 PM
