ABB ACS180 User Manual

Additional parameter data 311
22.32 Constant speed 7 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.41 Speed ref safe Real -30000.00…30000.00 rpm 100 = 1 rpm
22.42 Jogging 1 ref Real -30000.00…30000.00 rpm 100 = 1 rpm
22.43 Jogging 2 ref Real -30000.00…30000.00 rpm 100 = 1 rpm
22.51 Critical speed function PB 0000h…FFFFh - 1 = 1
22.52 Critical speed 1 low Real -30000.00…30000.00 rpm 100 = 1 rpm
22.53 Critical speed 1 high Real -30000.00…30000.00 rpm 100 = 1 rpm
22.54 Critical speed 2 low Real -30000.00…30000.00 rpm 100 = 1 rpm
22.55 Critical speed 2 high Real -30000.00…30000.00 rpm 100 = 1 rpm
22.56 Critical speed 3 low Real -30000.00…30000.00 rpm 100 = 1 rpm
22.57 Critical speed 3 high Real -30000.00…30000.00 rpm 100 = 1 rpm
22.71 Motor potentiometer function List 0…3, 5 - 1 = 1
22.72 Motor potentiometer initial
value
Real -32768.00…32767.00 - 100 = 1
22.73 Motor potentiometer up
source
Binary src --1 = 1
22.74 Motor potentiometer down
source
Binary src --1 = 1
22.75 Motor potentiometer ramp
time
Real 0.0…3600.0 s 10 = 1 s
22.76 Motor potentiometer min
value
Real -32768.00…32767.00 - 100 = 1
22.77 Motor potentiometer max
value
Real -32768.00…32767.00 - 100 = 1
22.80 Motor potentiometer ref act Real -32768.00…32767.00 - 100 = 1
22.86 Speed reference act 6 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.87 Speed reference act 7 Real -30000.00…30000.00 rpm 100 = 1 rpm
23 Speed reference ramp
23.01 Speed ref ramp input Real -30000.00…30000.00 rpm 100 = 1 rpm
23.02 Speed ref ramp output Real -30000.00…30000.00 rpm 100 = 1 rpm
23.11 Ramp set selection Binary src --1 = 1
23.12 Acceleration time 1 Real 0.000 …1800.000 s 1000 = 1 s
23.13 Deceleration time 1 Real 0.000 …1800.000 s 1000 = 1 s
23.14 Acceleration time 2 Real 0.000 …1800.000 s 1000 = 1 s
23.15 Deceleration time 2 Real 0.000 …1800.000 s 1000 = 1 s
23.20 Acc time jogging Real 0.000 …1800.000 s 1000 = 1 s
23.21 Dec time jogging Real 0.000 …1800.000 s 1000 = 1 s
23.23 Emergency stop time Real 0.000 …1800.000 s 1000 = 1 s
23.28 Variable slope enable Real 2…30000 ms 1 = 1 ms
23.29 Variable slope rate Real 2…30000 ms 1 = 1 ms
23.32 Shape time 1 Real 0.000 …1800.000 s 1000 = 1 s
23.33 Shape time 2 Real 0.000 …1800.000 s 1000 = 1 s
No. Name Type Range Unit FbEq32
ACS180 FW.book Page 311 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
