Technical data
113
Technical data
What this chapter contains
This chapter contains the technical specifications of the drive, for example, the
ratings, sizes and technical requirements, provisions for fulfilling the requirements
for CE and other markings, and warranty policy.
IEC data
Ratings
The IEC ratings for the ACS800-07 with 50 Hz and 60 Hz supplies are given below.
The symbols are described below the table.
ACS800-07 type Nominal ratings No-
overload
use
Light-overload use Heavy-duty use Frame
size
Air flow Heat
dissipation
I
cont.max
A
I
max
A
P
cont.max
kW
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW m
3
/h W
Three-phase supply voltage 380 V, 400 V or 415 V
-0075-3 145 170 75 141 75 100 45 R5 405 1440
-0100-3 166 202 90 155 75 115 55 R6 405 1940
-0120-3 202 282 110 184 90 141 75 R6 405 2310
-0135-3 225 326 110 220 110 163 90 R6 405 2810
-0165-3 260 326 132 254 132 215 110 R6 405 3260
-0205-3 290 351 160 285 160 234 132 R6 405 4200
-0260-3 445 588 200 440 200 340 160 R8 1220 6600
-0320-3 521 588 250 516 250 370 200 R8 1220 7150
-0400-3 602 840 315 590 315 477 250 R8 1220 8100
-0440-3 693 1017 355 679 355 590
2)
315 R8 1220 8650
-0490-3 720 1017 400 704 400 635
3)
355 R8 1220 9100
