ABB ACS800-U7 User Manual

Technical data
118
Ultrarapid (aR) fuses
A
2
s value for -7 units at 660 V
1)
minimum short-circuit current of the installation
ACS800-07
size
Input
current
A
Min. short-
circuit
current
1)
Fuse
AA A
2
s V Manufacturer Type DIN 43620 Size
Three-phase supply voltage 380 V, 400 V or 415 V
-0075-3 142 1630 315 80 500 690 Bussmann 170M1572 DIN000
-0100-3 163 1280 315 46 500 690 Bussmann 170M3817 DIN1*
-0120-3 198 1810 400 105 000 690 Bussmann 170M3819 DIN1*
-0135-3 221 2210 500 145 000 690 Bussmann 170M5810 DIN2*
-0165-3 254 2620 550 190 000 690 Bussmann 170M5811 DIN2*
-0205-3 286 2620 550 190 000 690 Bussmann 170M5811 DIN2*
-0260-3 438 4000 800 465 000 690 Bussmann 170M6812 DIN3
-0320-3 501 5550 1000 945 000 690 Bussmann 170M6814 DIN3
-0400-3 581 7800 1250 1 950 000 690 Bussmann 170M8554 DIN3
-0440-3 674 8850 1400 3 900 000 690 Bussmann 170M8555 DIN3
-0490-3 705 8850 1400 3 900 000 690 Bussmann 170M8555 DIN3
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V or 500 V
-0105-5 142 1630 315 80500 690 Bussmann 170M1572 DIN000
-0120-5 155 1280 315 46 500 690 Bussmann 170M3817 DIN1*
-0140-5 180 1810 400 105 000 690 Bussmann 170M3819 DIN1*
-0165-5 222 2210 500 145 000 690 Bussmann 170M5810 DIN2*
-0205-5 256 2620 550 190 000 690 Bussmann 170M5811 DIN2*
-0255-5 286 2620 550 190 000 690 Bussmann 170M5811 DIN2*
-0320-5 424 4000 800 465 000 690 Bussmann 170M6812 DIN3
-0400-5 498 5550 1000 945 000 690 Bussmann 170M6814 DIN3
-0440-5 543 7800 1250 1 950 000 690 Bussmann 170M8554 DIN3
-0490-5 590 7800 1250 1 950 000 690 Bussmann 170M8554 DIN3
-0550-5 669 8850 1400 3 900 000 690 Bussmann 170M8555 DIN3
-0610-5 702 8850 1400 3 900 000 690 Bussmann 170M8555 DIN3
Three-phase supply voltage 525 V, 550 V, 575 V, 600 V, 660 V or 690 V
-0070-7 79 520 125 8 500 690 Bussmann 170M1568 000
-0100-7 91 695 160 16 000 690 Bussmann 170M1569 000
-0120-7 112 750 200 15 000 690 Bussmann 170M3815 1*
-0145-7 131 1520 350 68 500 690 Bussmann 170M3818 DIN1*
-0175-7 162 1520 350 68 500 690 Bussmann 170M3818 DIN1*
-0205-7 186 1610 400 74 000 690 Bussmann 170M5808 DIN2*
-0260-7 217 1610 400 74 000 690 Bussmann 170M5808 DIN2*
-0320-7 298 3010 630 275 000 690 Bussmann 170M5812 DIN2*
-0400-7 333 2650 630 210 000 690 Bussmann 170M6810 DIN3
-0440-7 377 4000 800 465 000 690 Bussmann 170M6812 DIN3
-0490-7 423 4790 900 670 000 690 Bussmann 170M6813 DIN3
-0550-7 468 4790 900 670 000 690 Bussmann 170M6813 DIN3
-0610-7 533 5550 1000 945 000 690 Bussmann 170M6814 DIN3
00096931-H.22, 00556489
