ABB ACS800-U7 User Manual

Technical data
119
Optional gG fuses
* rated breaking capacity only up to 50 kA
1)
minimum short-circuit current of the installation
ACS800-07
size
Input current Min. short-
circuit
current
1)
Fuse
AAAA
2
s V Manufacturer Type IEC size
Three-phase supply voltage 380 V, 400 V or 415 V
-0075-3 142 2400 160 200000 500 ABB Control OFAF00H160 00
-0100-3 163 2850 200 350 000 500 ABB Control OFAF1H200 1
-0120-3 198 3300 224 420 000 500 ABB Control OFAF1H224 1
-0135-3 221 3820 250 550 000 500 ABB Control OFAF1H250 1
-0165-3 254 4510 315 1100000 500 ABB Control OFAF2H315 2
-0205-3 286 4510 315 1100000 500 ABB Control OFAF2H315 2
-0260-3 438 8280 500 2 900 000 500 ABB Control OFAF3H500 3
-0320-3 501 10200 630 4 000 000 500 ABB Control OFAF3H630 3
-0400-3 581 10200 630 4 000 000 500 ABB Control OFAF3H630 3
-0440-3 674 13500 800 7 400 000 500 ABB Control OFAF3H800 3
-0490-3 705 13500 800 7 400 000 500 ABB Control OFAF3H800 3
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V or 500 V
-0105-5 142 2400 160 200000 500 ABB Control OFAF00H160 00
-0120-5 155 2850 200 350 000 500 ABB Control OFAF1H200 1
-0140-5 180 2850 200 350 000 500 ABB Control OFAF1H200 1
-0165-5 222 3820 250 550 000 500 ABB Control OFAF1H250 1
-0205-5 256 4510 315 1100000 500 ABB Control OFAF2H315 2
-0255-5 286 4510 315 1100000 500 ABB Control OFAF2H315 2
-0320-5 424 8280 500 2 900 000 500 ABB Control OFAF3H500 3
-0400-5 498 10200 630 4 000 000 500 ABB Control OFAF3H630 3
-0440-5 543 10200 630 4 000 000 500 ABB Control OFAF3H630 3
-0490-5 590 10200 630 4 000 000 500 ABB Control OFAF3H630 3
-0550-5 669 13500 800 7 400 000 500 ABB Control OFAF3H800 3
-0610-5 702 13500 800 7 400 000 500 ABB Control OFAF3H800 3
Three-phase supply voltage 525 V, 550 V, 575 V, 600 V, 660 V or 690 V
-0070-7 79 1050 80 52200 690 ABB Control OFAA0GG80 0
-0100-7 91 1480 100 93000 690 ABB Control OFAA1GG100 1
-0120-7 112 1940 125 126000 690 ABB Control OFAA1GG125 1
-0145-7 131 2400 160 220000 690 ABB Control OFAA1GG160 1
-0175-7 162 2850 200 350000 690 ABB Control OFAA1GG200 1
-0205-7 186 3820 250 700000 690 ABB Control OFAA2GG250 2
-0260-7 217 3820 250 700 000 690 ABB Control OFAA2GG250 2
-0320-7 298 4510 315 820 000 690 ABB Control OFAA2GG315 2
-0400-7 333 6180 400 1 300 000 690 ABB Control OFAA3GG400 3
-0440-7 377 8280 500 3 800 000 690 ABB Control OFAA3H500 3
-0490-7 423 8280 500 3 800 000 690 ABB Control OFAA3H500 3
-0550-7 468 8280 500 3 800 000 690 ABB Control OFAA3H500 3
-0610-7 533 10800 630 10 000 000 690 Bussmann 630NH3G-690 * 3
00096931-H.22, 00556489
