ABB ACS800-U7 User Manual

Technical data
130
Cooling
Method Internal fan, flow direction from front to top
Filter material Inlet (door) Outlet (roof)
IP22 / IP42 units airTex G150
288mmx292mm
688 mm x 521 mm
-
IP54 units Luftfilter/airComp 300-50
288 mm x 292 mm
688 mm x 521 mm
Luftfilter/airTex G150
2 pcs: 398 mm x 312 mm
Free space around the unit See Free space around the unit.
Cooling air flow See IEC data.
Degrees of protection
IP21 (UL type 1), IP22 (UL type 1), IP42 (UL type 2),
IP54 (UL type 12 for indoor use only), IP54R
Ambient conditions
Environmental limits for the drive are given below. The drive is to be used in a heated,
indoor, controlled environment.
Operation
installed for stationary use
Storage
in the protective package
Transportation
in the protective package
Installation site altitude 0 to 4000 m (13123 ft) above
sea level [above 1000 m
(3281 ft), see section
Derating].
Cabinets with option +Q968:
0to2000m (6562ft)
--
Air temperature -15 to +50 °C (5 to 122 °F).
No frost allowed. See
section Derating.
-40 to +70 °C
(-40 to +158 °F)
-40 to +70 °C
(-40 to +158 °F)
Relative humidity 5 to 95% Max. 95% Max. 95%
No condensation allowed. Maximum allowed relative humidity is 60% in the presence of
corrosive gases.
Contamination levels
(IEC 60721-3-3,
IEC 60721-3-2,
IEC 60721-3-1)
No conductive dust allowed.
Boards without coating:
Chemical gases: Class 3C1
Solid particles: Class 3S2
Boards with coating:
Chemical gases: Class 3C2
Solid particles: Class 3S2
Boards without coating:
Chemical gases: Class 1C2
Solid particles: Class 1S3
Boards with coating:
Chemical gases: Class 1C2
Solid particles: Class 1S3
Boards without coating:
Chemical gases: Class 2C2
Solid particles: Class 2S2
Boards with coating:
Chemical gases: Class 2C2
Solid particles: Class 2S2
Atmospheric pressure 70 to 106 kPa
0.7 to 1.05 atmospheres
70 to 106 kPa
0.7 to 1.05 atmospheres
60 to 106 kPa
0.6 to 1.05 atmospheres
Vibration (IEC 60068-2) Max. 1 mm (0.04 in.)
(5 to 13.2 Hz),
max. 7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz) sinusoidal
Max. 1 mm (0.04 in.)
(5 to 13.2 Hz),
max. 7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz) sinusoidal
Max. 3.5 mm (0.14 in.)
(2 to 9 Hz),
max. 15 m/s
2
(49 ft/s
2
)
(9 to 200 Hz) sinusoidal
Shock (IEC 60068-2-27) Not allowed Max. 100 m/s
2
(330 ft./s
2
),
11 ms
Max. 100 m/s
2
(330 ft./s
2
),
11 ms
Free fall Not allowed 100 mm (4 in.) for weight
over 100 kg (220 lb)
100 mm (4 in.) for weight
over 100 kg (220 lb)
