ABB ACS800-U7 User Manual

Technical data
123
NEMA data
Ratings
The NEMA ratings for the ACS800-U7 and ACS800-07 with 60 Hz supplies are
given below. The symbols are described below the table. For sizing, derating and
50 Hz supplies, see section IEC data.
1)
available if ambient temperature is less than 30 °C (86 °F). If ambient temperature is 40 °C (104 °F),
I
2N
is 286 A.
2)
special 4-pole high-efficiency NEMA motor
3)
50% overload is allowed for one minute every five minutes if ambient temperature is less than 30 °C
(86 °F). 40% overload is allowed if ambient temperature is 40 °C (104 °F).
4)
available if ambient temperature is less than 30 °C (86 °F). If ambient temperature is 40 °C
(104 °F), I
2N
is 704 A.
*
higher value available if output frequency is above 41 Hz
**
ACS800-U7 types only
ACS800-U7 type
ACS800-07 type
I
max
Normal use Heavy-duty use Frame
size
Air flow Heat
dissipation
A
I
2N
A
P
N
hp
I
2hd
A
P
hd
hp ft
3
/min BTU/Hr
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V
-0100-5 164 124 100 96 75 R6 238 6610
-0120-5 202 157 125 124 100 R6 238 7890
-0140-5 282 180 150 156 125 R6 238 9600
-0165-5 326 220 150 165 125 R6 238 11140
-0205-5 326 245 200 215 150 R6 238 12980
-0270-5 ** 480 316 250 240 200 R8 718 15350
-0300-5 ** 568 361 300 302 250 R8 718 18050
-0320-5 588 435 350 340 250 R8 718 23250
-0400-5 588 510 400 370 300 R8 718 26650
-0440-5 840 545 450 490 400 R8 718 25950
-0490-5 840 590 500 515
3)
450 R8 718 27600
-0550-5 1017 670 550 590
3)
500 R8 718 31100
-0610-5 1017 718
4)
600 590
3)
500 R8 718 33000
Three-phase supply voltage 525 V, 575 V or 600 V
-0070-7 104 73 60 54 50 R6 238 4200
-0100-7 124 86 75 62 60 R6 238 5650
-0120-7 172 108 100 86 75 R6 238 6700
-0145-7 190 125 125 99 100 R6 238 9100
-0175-7 245 155 150 131 125 R6 238 11850
-0205-7 245 192 200 147 150 R6 238 14300
-0260-7 326 175/212* 150/200* 163 150 R7 318 16400
-0320-7 433 290 300 216 200 R8 718 21050
-0400-7 548 344 350 274 250 R8 718 22750
-0440-7 656 387 400 328 350
2)
R8 718 25300
-0490-7 775 426 450 387 400 R8 718 28900
-0550-7 853 482 500 426 450 R8 718 28350
-0610-7 964 537 500 482 500 R8 718 33300
