Technical data
122
Cable entries
Mains, motor and brake resistor cable terminal sizes (per phase), maximum
accepted cable and tightening torques are given below.
1)
external brake resistor (+D150) and DC connection terminals: wire size 6…70 mm
2
, screw M8,
tightening torque 15 Nm
2)
external brake resistor (+D150) and DC connection terminals: wire size 95…185 mm
2
, screw M10,
tightening torque 40 Nm
Dimensions, weights and noise
1)
in marine applications (+C121) extra height: 10 mm from the fastening bar at the bottom of the
cabinet
2)
extra width for units with brake resistors (+D151): SAFURxxxFxxx 400 mm, 2xSAFURxxxFxxx
800 mm, 4xSAFURxxxFxxx 1600 mm
3)
extra width for units with EMC filter (+E202): 200 mm
4)
extra width for units with EMC filter (+E202): 400 mm
5)
in marine applications (+C121) depth with fastening bars: 700 mm
Frame
size
L1, L2, L3, U2, V2, W2, UDC+/R+, UDC-, R- Earthing PE
Number of
holes per
phase
Hole
diameter
Max. wire
size
Screw Tightening
torque
Screw Tightening
torque
mm mm
2
Nm Nm
R5
1)
1 60 185 M10 20...40 M10 30...44
R6
2)
1 60 185 M10 20...40 M10 30...44
R7 3 60 1×240 or
2×185
M12 50...75 M10 30...44
R8 3 60 3×240 M12 50...75 M10 30...44
Frame size Height
1)
Width
2)
Depth
5)
Weight Noise
IP21/22/42 IP54
mm mm mm mm kg dB
R5 2130 2315 430 689 300 63
R6 2130 2315 430 689 300 63
R7 2130 2315 830
3)
689 400 71
R8 2130 2315 830
4)
689 500 72
00184674 -J
