Operation principle and hardware description
23
Type designation key
The type designation key contains information on the specifications and
configuration of the drive. The first digits from left express the basic configuration
(eg, ACS800-07-0170-5). The optional selections are given thereafter, separated by
+ signs (eg, +E202). The main selections are described below. Not all selections are
available for all types. For more information, refer to ACS800 Ordering Information
(EN code: 64556568, available on request).
Selection Alternatives
Product series ACS800 product series
Type 07 cabinet built. When no options are selected: IP21 (UL type1),
main switch fuse with aR fuses, 230 VAC control voltage, control
panel CDP312R, no EMC filter, standard software, bottom entry
and exit of cables, cable lead through entry, boards without
coating, one set of default language documents.
U7 cabinet built (USA). When no options are selected: UL type1
(IP21), US type main switch fuse, 115VAC control voltage, control
panel CDP312R, no EMC filter, standard software (US), top entry
and exit of cables, cable conduit entry, common mode filter in R8,
one set of default language documents.
Size See Technical data: IEC data or NEMA data.
Voltage range
(nominal rating in bold)
3 380/400/415 VAC
5 380/400/415/440/460/480/500 VAC
7 525/575/600/690 VAC
Optional selections Eg, ACS800-07-0170-5+E202
Degree of protection +B053 IP22 (UL type 1)
+B054 IP42 (UL type 2)
+B055 IP54 (UL type 12)
+B059 IP54R with connection to air outlet duct
Construction +C121 marine construction (reinforced mechanics and fastening,
marking of conductors according to class A1, door handles, self-
extinctive materials)
+C129 UL listed (for ACS800-07 units only): US type main switch fuse,
115 VAC control voltage, US cable conduit entry, all components
UL listed/recognized, max. supply voltage 600 V.
+C134 CSA marked. US/CSA type main switch fuse, bottom entry and
exit, 115 VAC control voltage, all components UL/CSA listed/
recognized, max. supply voltage 600 V.
Resistor braking +D150 brake chopper (external resistor)
+D151 brake resistor
Filter +E200 EMC/RFI filter for second environment TN (grounded) system
+E202 EMC/RFI filter for first environment TN (grounded) system,
restricted (A limits)
+E210 EMC/RFI filter for second environment TN/IT (grounded/
ungrounded) system
+E205 du/dt filter
+E206 sine filter
+E208 common mode filter
Line options +F250 line contactor
+F251 gG line fuses
