ABB ACS850 User Manual

Parameters 163
16.07 Param save Saves the valid parameter values to the permanent memory.
Note: A new parameter value is saved automatically when
changed from the PC tool or panel but not when altered
through a fieldbus adapter connection.
Done Save completed. 0
Save Save in progress. 1
16.09 User set sel Enables the saving and restoring of up to four custom sets of
parameter settings.
The set that was in use before powering down the drive is in
use after the next power-up.
Notes:
• Fieldbus adapter and encoder parameters (groups 50-53
and 90-93 respectively) are not part of the user parameter
sets.
• Any parameter changes made after loading a set are not
automatically stored – they must be saved using this
parameter.
No request Load or save operation complete; normal operation. 1
Load set 1 Load user parameter set 1. 2
Load set 2 Load user parameter set 2. 3
Load set 3 Load user parameter set 3. 4
Load set 4 Load user parameter set 4. 5
Save set 1 Save user parameter set 1. 6
Save set 2 Save user parameter set 2. 7
Save set 3 Save user parameter set 3. 8
Save set 4 Save user parameter set 4. 9
IO mode Load user parameter set using parameters 16.11 User IO sel
lo and 16.12 User IO sel hi.
10
16.10 User set log Shows the status of the user parameter sets (see parameter
16.09 User set sel). Read-only.
N/A No user sets have been saved. 0
Loading A user set is being loaded. 1
Saving A user set is being saved. 2
Faulted Invalid or empty parameter set. 4
Set1 IO act User parameter set 1 has been selected by parameters 16.11
User IO sel lo and 16.12 User IO sel hi.
8
Set2 IO act User parameter set 2 has been selected by parameters 16.11
User IO sel lo and 16.12 User IO sel hi.
16
Set3 IO act User parameter set 3 has been selected by parameters 16.11
User IO sel lo and 16.12 User IO sel hi.
32
Set4 IO act User parameter set 4 has been selected by parameters 16.11
User IO sel lo and 16.12 User IO sel hi.
64
Set1 par act User parameter set 1 has been loaded using parameter 16.09
User set sel.
128
Set2 par act User parameter set 2 has been loaded using parameter 16.09
User set sel.
256
Set3 par act User parameter set 3 has been loaded using parameter 16.09
User set sel.
512
No. Name/Value Description FbEq
