ABB ACS850 User Manual

Parameters 187
26.02 Const speed sel1 When bit 0 of parameter 26.01 Const speed func is 0
(Separate), selects a source that activates constant speed 1.
When bit 0 of parameter 26.01 Const speed func is 1
(Packed), this parameter and parameters 26.03 Const speed
sel2 and 26.04 Const speed sel3 select three sources whose
states activate constant speeds as follows:
DI1 Digital input DI1 (as indicated by 02.01 DI status, bit 0). 1073742337
DI2 Digital input DI2 (as indicated by 02.01 DI status, bit 1). 1073807873
DI3 Digital input DI3 (as indicated by 02.01 DI status, bit 2). 1073873409
DI4 Digital input DI4 (as indicated by 02.01 DI status, bit 3). 1073938945
DI5 Digital input DI5 (as indicated by 02.01 DI status, bit 4). 1074004481
DI6 Digital input DI6 (as indicated by 02.01 DI status, bit 5). 1074070017
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
26.03 Const speed sel2 When bit 0 of parameter 26.01 Const speed func is 0
(Separate), selects a source that activates constant speed 2.
When bit 0 of parameter 26.01 Const speed func is 1
(Packed), this parameter and parameters 26.02 Const speed
sel1 and 26.04 Const speed sel3 select three sources that
are used to activate constant speeds. See table at parameter
26.02 Const speed sel1.
DI1 Digital input DI1 (as indicated by 02.01 DI status, bit 0). 1073742337
DI2 Digital input DI2 (as indicated by 02.01 DI status, bit 1). 1073807873
DI3 Digital input DI3 (as indicated by 02.01 DI status, bit 2). 1073873409
DI4 Digital input DI4 (as indicated by 02.01
DI status, bit 3). 1073938945
DI5 Digital input DI5 (as indicated by 02.01 DI status, bit 4). 1074004481
DI6 Digital input DI6 (as indicated by 02.01 DI status, bit 5). 1074070017
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
26.04 Const speed sel3 When bit 0 of parameter 26.01 Const speed func is 0
(Separate), selects a source that activates constant speed 3.
When bit 0 of parameter 26.01 Const speed func is 1
(Packed), this parameter and parameters 26.02 Const speed
sel1 and 26.03 Const speed sel2 select three sources that
are used to activate constant speeds. See table at parameter
26.02 Const speed sel1.
DI1 Digital input DI1 (as indicated by 02.01 DI status, bit 0). 1073742337
No. Name/Value Description FbEq
Source defined
by par. 26.02
Source defined
by par. 26.03
Source defined
by par. 26.04
Constant speed active
000None
1 0 0 Constant speed 1
0 1 0 Constant speed 2
1 1 0 Constant speed 3
0 0 1 Constant speed 4
1 0 1 Constant speed 5
0 1 1 Constant speed 6
1 1 1 Constant speed 7
