ABB ACS880 Series Quick Start Up Guide

Drive configuration
Contents of this chapter
This chapter describes how to configure the drive for PROFIBUS DP or PROFINET control based on
ABB specific drives library ABB_DRIVE_LIB.
Overview
You can configure the drive for PROFIBUS DP or PROFINET control based on ABB specific drives
library ABB_DRIVE_LIB.
Set the drive parameters from the drive’s control panel or from drive-specific PC tool (DriveWindow Light
for ACS355 and ACS550, DriveStudio for ACS850 and ACSM1, Drive Composer for ACS380, ACS580
and ACS880, and DriveWindow for ACS800).
Note: All parameter settings are based on drive default settings. If the drive was parametrized previously,
return to default settings before continuing. It can be done by:
ACS355 and ACS550
Change macro (and then change back again) in parameter 99.02.
ACS800
Set parameter 99.03 APPLIC RESTORE to YES
ACS850 and ACSM1
Set parameter 16.04 Param restore to Restore defs
ACS380, ACS580 and ACS880
Set parameter 96.06 Parameter restore to Restore defaults
2

ABB ACS880 Series Specifications

General

Cooling Method	Air-cooled, liquid-cooled
Enclosure class	IP21, IP55
Mounting type	Wall-mounted
Control method	Direct torque control (DTC)
Braking chopper	Integrated or external
Communication	Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, overload, short circuit, overtemperature, earth fault
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Relative Humidity	5 ... 95 % (non-condensing)
Safety features	Safe torque off (STO)
